Kanish Metals stands out as a reliable manufacturer and supplier of Aluminium 6063 Forgings in Dubai, UAE, delivering top-notch products that align with global standards. Aluminium 6063 is a well-regarded alloy, celebrated for its remarkable corrosion resistance, sleek surface finish, and outstanding formability. Our forgings find their way into various industries that require lightweight yet robust materials with exceptional mechanical properties. Thanks to our state-of-the-art manufacturing facilities and rigorous quality checks, Kanish Metals guarantees precision, strength, and reliability, making us the go-to choice for clients in the construction, automotive, marine, and aerospace sectors both in the UAE and around the globe.
Aluminium 6063 Forgings are primarily made of aluminium, enhanced with magnesium and silicon to boost strength and corrosion resistance. This alloy typically includes 0.2–0.6% silicon, 0.45–0.9% magnesium, along with small amounts of iron, copper, manganese, and chromium. Mechanically, it boasts excellent tensile strength, good elongation, and impressive toughness, making it perfect for structural applications. Renowned for its high machinability and weldability, Aluminium 6063 remains stable under heat treatment, striking a balance between strength and ductility while ensuring durability in challenging conditions.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Al | Other Each | Others Total |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | Remainder | .05 | .015 |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
| UNS | WNR | DIN | EN | ISO | BS (OLD) | USA |
| A96063 | 3.32206 | AlMgSi0.5 | AW-AlMg0,7Si EN AW-6063 | AlMg0,7Si | HE9 | AA6063 |
Aluminum 5082 offers high strength, excellent corrosion resistance, good weldability, and enhanced fatigue resistance, making it ideal for custom forgings in marine, aerospace, and structural applications.
Aluminum 5082's workability, characterized by good machinability and medium strength, allows for easy shaping during forging. However, its relatively low work hardening rate may require careful temperature control.
Aluminium 6063 Forgings are widely embraced across various industries due to their versatility, lightweight nature, and durability. They are commonly used in architectural and structural applications like window frames, doors, roofing, and curtain walls, thanks to their appealing finish and resistance to corrosion. In the automotive and aerospace fields, they are prized for their ability to reduce weight without compromising strength and performance. Marine applications benefit from their seawater resistance, while the electrical and electronic sectors utilize them for conductive components. Their adaptability makes them an excellent choice for engineering and fabrication projects worldwide.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
