Kanish Metals is a well-established manufacturer and supplier of Aluminium 1060 forgings in Dubai, UAE, providing premium quality aluminium parts customized for broad industrial uses. Reputed to provide precision-forged components of superior surface finish and dimensional tolerance, Kanish Metals supplies industries with lightweight, corrosion-proof, and superior conductive material needs. Aluminium 1060, boasting of high purity and formability, is best suited for applications involving electrical conductivity and corrosion resistance. With a focus on quality, customer satisfaction, and punctual delivery, the company has established a strong presence in the domestic and overseas markets.
Aluminium 1060 forgings consist of about 99.6% aluminium, which makes them have very good electrical conductivity, high thermal conductivity, and excellent corrosion resistance. The alloy is easy to form and weld, though it has fairly low mechanical strength as compared to the rest of the aluminium alloys. Common mechanical properties involve tensile strength around 95 MPa and high elongation, which provides very good ductility. These traits make Aluminium 1060 ideal for non-load-bearing use where conductivity and endurance against atmospheric conditions are critical over strength, particularly in electrical and chemical equipment industries.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Element | Content (%) |
|---|---|
| Aluminium / Aluminum, Al | 99.60 (min) |
| Properties | Metric | Imperial |
|---|---|---|
| Elastic modulus | 70-80 GPa | 10152-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| STANDARD | UNS |
| Aluminium 1060 | A91060 |
Aluminum 1060 is not ideal for high-temperature forging applications due to its low strength and relatively low melting point. It is more suited for applications requiring excellent corrosion resistance and formability.
Aluminum 1060 offers high corrosion resistance, excellent workability, good weldability, and enhanced electrical conductivity, making it ideal for custom forgings in industries requiring lightweight, durable, and malleable components.
Aluminium 1060 forgings find extensive applications in industries demanding high electrical conductivity, corrosion resistance, and ease of fabrication. Typical uses include electrical conductors, transformer windings, cable sheathing, and parts in power transmission systems. The alloy is also employed in the chemical and food industries because it is non-toxic and chemically resistant, which makes it perfect for processing equipment, containers, and storage tanks. In the architectural industry, it finds use in ornaments and facades. Its high formability also makes it perfect for tailor-made forged components in HVAC systems and signage.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
