Kanish Metals stands out as a top manufacturer and supplier of high-quality Copper Nickel Square Bars in Dubai, UAE. We’re recognized for our commitment to quality, precision, and durability. With a solid foothold in the Middle East market, we offer copper-nickel products that adhere to international standards, ensuring they perform exceptionally well even in tough and corrosive conditions. Our Copper Nickel Square Bars find their place in marine, chemical, and industrial sectors, boasting remarkable resistance to seawater and high temperatures. Supported by cutting-edge manufacturing technology and a talented workforce, Kanish Metals is dedicated to providing dependable, cost-effective, and customizable copper-nickel solutions for a variety of engineering needs.
At Kanish Metals, our Copper Nickel Square Bars come in standard Cu-Ni alloys like 90/10 (90% Copper, 10% Nickel) and 70/30 (70% Copper, 30% Nickel). These bars are known for their exceptional corrosion resistance, particularly in saltwater and acidic settings. Their mechanical properties include a tensile strength that ranges from 275 to 500 MPa, yield strength between 100 to 350 MPa, and elongation rates of 30% to 40%. The square shape not only ensures structural integrity but also makes machining a breeze, making them perfect for precision engineering applications where strength, corrosion resistance, and formability are key.
| Standard | ASTM B111, ASME SB111 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000 PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000 PSi |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed / pickled |
| CG | Centreless ground | HF | Hot finished |
| ST | Smooth turned | PR | Peeled / reeled |
| CD | Cold drawn | P | Polished |
| P&T | Peeled / turned | RT | Rough turned and peeled |
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
Copper Nickel Square Bars are widely utilized in marine applications like boat building, seawater piping systems, condenser plates, and heat exchangers, thanks to their impressive resistance to saltwater corrosion and biofouling. In the oil and gas industry, they play a crucial role in offshore structures and platforms. These bars are also essential in power plants and desalination units, where high thermal conductivity and mechanical strength are vital. Furthermore, they find applications in chemical processing equipment, automotive components, and more, showcasing their versatility across various sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
