Kanish Metals is a well-established manufacturer and supplier of Aluminium 1070 forgings in Dubai, UAE. With experience in manufacturing high-purity aluminium parts, the company supplies precision-forged components that are in compliance with the standards of different industrial uses. Aluminium 1070 is recognized for its great workability, corrosion resistance, and high electrical conductivity, which makes it suitable for specialized industries. Powered by cutting-edge machinery and an expert team, Kanish Metals provides forgings that are compliant with high standards of quality and customer requirements. Their commitment to innovation and timely delivery has established them as a go-to supplier for aluminium forging solutions in the UAE and around the globe.
Aluminium 1070 forgings are produced using commercially pure aluminium with about 99.7% aluminium content. The alloy is excellent in thermal and electrical conductivity, has high corrosion resistance, and good formability. The mechanical properties are somewhat low tensile strength but very good ductility and impact resistance, which can be enhanced by cold working. Aluminium 1070 generally has a typical tensile strength of about 90 MPa, elongation of 35%, and very good performance without heat treatment. These properties make it best suited for uses where electrical performance and environmental resistance are more important than strength.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Element | Aluminum, Al | Iron, Fe | Silicon, Si | Zinc, Zn | Vanadium, V | Copper, Cu | Titanium, Ti | Magnesium, Mg | Manganese, Mn | Other (each) |
|---|---|---|---|---|---|---|---|---|---|---|
| Content (%) | ≥ 99.7 | ≤ 0.25 | ≤ 0.20 | ≤ 0.040 | ≤ 0.050 | ≤ 0.040 | ≤ 0.030 | ≤ 0.030 | ≤ 0.030 | ≤ 0.030 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 95 MPa | 13778 psi |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 1070 | A91070 | 3.0275 |
Aluminum 1070 is not ideal for high-temperature forging applications due to its relatively low melting point and limited strength at elevated temperatures. Alloys like 7075 or 2618 are better suited.
Aluminum 1070 offers excellent corrosion resistance, high electrical conductivity, good formability, and high purity, making it ideal for custom forgings in applications requiring strength and durability with minimal impurities.
Aluminium 1070 forgings have found extensive use in applications that demand high thermal and electrical conductivity and superior corrosion resistance. Typical applications include transformer parts, electrical bus bars, heat exchangers, and conductive components in power distribution equipment. In the food and chemical processing businesses, it is utilized for machinery that requires high resistance to corrosion and purity. Its ability to be formed makes it ideal for forged parts in architectural and decorative uses. Aluminium 1070 is also utilized in the automotive and aerospace industries for non-structural parts where weight-light and conductivity are necessary.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
