Kanish Metals is a prominent producer and distributor of Hastelloy W Bars and Rods in Dubai, UAE, providing high-quality materials for critical welding and high-temperature services. Hastelloy W is a nickel-based alloy strengthened by solid solution and was especially designed for welding and fabrication in harsh conditions. Kanish Metals provides accurately produced bars and rods conforming to international standards of quality, providing superior mechanical performance as well as corrosion resistance. Renowned for reliable service, customization, and timely delivery, Kanish Metals caters to sectors like aerospace, power generation, chemical processing, and defense industries within the UAE, as well as international markets.
Hastelloy W contains mostly nickel (approximately 65%), with substantial additions of molybdenum (~28%), iron, and trace amounts of cobalt and chromium. This alloy enjoys superior weldability and retains strength and corrosion resistance when used in high-temperature applications. It provides a tensile strength of about 690–860 MPa and possesses good toughness and ductility. Hastelloy W is resistant to cracking while welding and is specially effective in protecting metal constructions exposed to reducing and oxidizing environments, as well as high thermal cycling conditions.
| Standards : | AMS 5755, AMS 5786, AWS A5.14 & ASME SFA 5.14 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P | Cu |
| 0.12 | 1.0 | 1.0 | 0.03 | ≤2.5 | – | 4.0-6.0 | 4.00 – 7.00 | 23-26 | 0.04 | ≤0.5 |
| Yield strength (MPa) | Tensile strength(MPa) | Impact test | Elongation (%) | Reduction in cross section on fracture (%) | As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 765 (≥) | 352 (≥) | 31 | 24 | 23 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 214 |
| STANDARD | WERKSTOFF NR. | UNS |
| Hastelloy W | – | N10004 |
Hastelloy W Bars offer exceptional resistance to corrosion, especially in harsh chemical environments, along with high strength and excellent weldability. They are ideal for high-temperature applications due to their thermal stability.
Yes, Hastelloy W rods can be welded. They are known for their excellent weldability, making them suitable for high-temperature and corrosive environments.
Hastelloy W rods are available in a range of diameters, typically from 1/8 inch to several inches, and can be supplied in various finishes, including mill, polished, and ground. Custom sizes and finishes can also be provided based on specific requirements.
Hastelloy W Bars and Rods are primarily used in industries requiring superior resistance to high temperatures, corrosion, and oxidation. These materials are ideal for applications in chemical processing, petrochemical, and power generation industries, where components are exposed to harsh environments. Hastelloy W is highly resistant to pitting, crevice corrosion, and stress corrosion cracking, making it suitable for use in heat exchangers, reactor cores, and turbine components. Its excellent mechanical properties at elevated temperatures also make it a choice material for aerospace, marine, and pollution control applications. These bars and rods are frequently used in highly demanding industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
