Copper Nickel Flat Bars

Kanish Metals stands out as a leading manufacturer and supplier of top-notch Copper Nickel Flat Bars in Dubai, UAE. Known for our commitment to quality and reliability, we provide products that not only meet international standards but also address a wide range of industrial requirements. Our Copper Nickel Flat Bars are meticulously crafted to perform exceptionally well in challenging environments, particularly within marine and chemical sectors. With a wealth of technical knowledge, state-of-the-art manufacturing facilities, and a strong focus on customer satisfaction, we guarantee prompt delivery, competitive pricing, and tailored solutions for every project. Trust Kanish Metals for unparalleled quality and service in copper-nickel solutions.

CUNI 70/30 Flat Bar Exporter in UAE, Copper Nickel Flat Bar Size, UNS C70600 Flat Rod Stockist in Dubai, Cunifer 90/10 Flat Bar Supplier in UAE, CuNi 90/10 Flat bar Distributor in Sharjah, Copper Nickel Flat Bar Stockist Ajman, 90/10 Copper Nickel Flat Bar Price in Ajman, CuNi Industrial Flat Bars Jebel Ali, Cu-Ni Alloy Flat Bars and Rods Supplier in Sharjah, CUNI Flat Bars Supplier in Jebel Ali, DIN 2.0882 Flat Rod Exporter in Abu Dhabi

70/30 Copper Nickel Flat Bar

Copper Nickel Flat Bar

90/10 Copper Nickel Flat Bar

What is Copper Nickel Flat Bars?

Kanish Metals’ Copper Nickel Flat Bars are primarily made of copper (Cu) and nickel (Ni), featuring standard alloys like 90/10 (Cu-90%, Ni-10%) and 70/30 (Cu-70%, Ni-30%). These bars are known for their remarkable corrosion resistance, particularly in saltwater settings. Their mechanical properties include impressive tensile strength, good ductility, and excellent thermal stability. Typical measurements show a tensile strength ranging from 275-500 MPa, yield strength between 100-350 MPa, and elongation of 30-40%. These characteristics make Copper Nickel Flat Bars perfect for applications in pressure vessels, heat exchangers, and condenser systems.

70/30 Copper Nickel Flat Bar Exporter in UAE, Cupro Nickel Flat Rods Exporter in Al Ain, Copper Nickel Cold Drawn Flat Bar Manufacturer in Ajman, Cupro Nickel Cold Rolled Flat Bar Distributor in UAE, Alloy Copper Nickel Flat Bar Dealer in Abu Dhabi, Cupro Nickel Bright Flat Bar Supplier in Sharjah, Copper Nickel Flat Bars and Rods Stockist in Jebel Ali, 90/10 Copper Nickel Flat Bars Size Chart, Cupro Nickel 70/30 Cold Drawn Flat Bar Manufacturer in Dubai

Copper Nickel Flat Bars Specifications

tandards: EN, DIN, JIS, ASTM, BS, ASME, AISI

Size: 5 mm to 200 mm

Length : 100 mm to 3660 mm Long

Specifications : ASTM / ASME SB 111

Form : Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.

Finish : Bright, Polish & Black

Chemical Composition of Copper Nickel Flat Bars Rods

Grade	Mn	Cu	Pb	Fe	Ni	Zn
90/10	1.0 max	88.6 min	0.5 max	1.8 max	9-11 max	1 max
70/30	1 max	65.0 min	0.5 max	0.4-1.0	29-33	1 max

Mechanical Properties of Copper Nickel Flat Bars

Grade	Melting point	Density	Tensilestrength	Elongation	Yieldstrength(0.2%Offset)
90/10	2260°F	8.8g/cm3	50000 PSi	30%	20000 PSi
70/30	2260°F	0.323 lb/in3 at 68°F	50000 PSi	30%	20000 PSi

You Need Our Support, to Have Any Projects?

Test Certificate

Why Kanish Metals?

Packaging

Cupronickel Flat Bar Stock Surface Finishes

BD	Bright drawn	SRE	Slit rolled edge
CF	Cold finished	HRAP	Hot rolled annealed / pickled
CG	Centreless ground	HF	Hot finished
ST	Smooth turned	PR	Peeled / reeled
CD	Cold drawn	P	Polished
P&T	Peeled / turned	RT	Rough turned and peeled

Size chart of Copper Nickel Flat Bar

Flat bar – metric sizes ( weights )
Flat size	Standard length (metres)	KG’s / metre	Colour code
16 x 3	6.0	0.38	Blue
13 x 3	6.0	0.31	Blue
13 x 5	6.0	0.46	Orange
16 x 5	6.0	0.64	Orange
20 x 3	6.0	0.48	Blue
16 x 8	6.0	1.03	Red
20 x 5	6.0	0.81	Orange
20 x 10	6.0	1.61	Yellow
20 x 6	6.0	0.97	White
25 x 3	6.0	0.60	Blue
25 x 6	6.0	1.21	White
10 x 3	6.0	0.24	Blue
25 x 5	6.0	1.01	Orange
25 x 8	6.0	1.61	Red
25 x 12	6.0	2.41	Pink
25 x 10	6.0	2.01	Yellow
32 x 3	6.0	0.77	Blue
32 x 6	6.0	1.55	White
32 x 5	6.0	1.29	Orange
32 x 8	6.0	2.06	Red
32 x 12	6.0	3.09	Pink
32 x 10	6.0	2.58	Yellow
40 x 3	6.0	0.97	Blue
40 x 6	6.0	1.93	White
40 x 5	6.0	1.61	Orange
40 x 8	6.0	2.58	Red
40 x 12	6.0	3.86	Pink
40 x 10	6.0	3.22	Yellow
40 x 16	6.0	5.15	Grey
50 x 3	6.0	1.21	Blue
40 x 20	6.0	6.14	Green
50 x 5	6.0	2.01	Orange
50 x 8	6.0	3.22	Red
50 x 6	6.0	2.41	White
50 x 10	6.0	4.02	Yellow
50 x 16	6.0	6.44	Grey
50 x 12	6.0	4.83	Pink
50 x 20	6.0	8.05	Green
65 x 3	6.0	1.57	Blue
50 x 25	6.0	10.1	Purple
65 x 5	6.0	2.62	Orange
65 x 8	6.0	4.18	Red
65 x 6	6.0	3.14	White
65 x 10	6.0	5.23	Yellow
65 x 16	6.0	8.37	Grey
65 x 12	6.0	6.28	Pink
65 x 20	6.0	10.5	Green
75 x 5	6.0	3.02	Orange
65 x 25	6.0	13.1	Purple
75 x 6	6.0	3.62	White
75 x 10	6.0	6.04	Yellow
75 x 8	6.0	4.83	Red
75 x 12	6.0	7.24	Pink
75 x 20	6.0	12.1	Green
75 x 16	6.0	9.66	Grey
75 x 25	6.0	15.1	Purple
90 x 5	6.0	3.62	Orange
75 x 40	6.0	24.1	Yellow
90 x 6	6.0	4.35	White
90 x 10	6.0	7.24	Yellow
90 x 8	6.0	5.79	Red
90 x 12	6.0	8.69	Pink
100 x 6	6.0	4.83	White
100 x 5	6.0	4.02	Orange
100 x 8	6.0	6.44	Red
100 x 12	6.0	9.66	Pink
100 x 10	6.0	8.05	Yellow
100 x 16	6.0	12.9	Grey
100 x 25	6.0	20.1	Purple
100 x 20	6.0	16.1	Green
100 x 50	6.0	40.2	Green
110 x 8	6.0	7.08	Red
110 x 6	6.0	5.31	White
110 x 10	6.0	8.85	Yellow
130 x 5	6.0	5.23	Orange
110 x 12	6.0	10.6	Pink
130 x 6	6.0	6.28	White
130 x 10	6.0	10.5	Yellow
130 x 8	6.0	8.37	Red
130 x 12	6.0	12.6	Pink
130 x 20	6.0	20.9	Green
130 x 16	6.0	16.7	Grey
130 x 25	6.0	26.2	Purple
150 x 6	6.0	7.24	White
150 x 5	6.0	6.04	Orange
150 x 8	6.0	9.66	Red
150 x 12	6.0	14.5	Pink
150 x 10	6.0	12.1	Yellow
150 x 16	6.0	19.3	Grey
150 x 25	6.0	30.1	Purple
150 x 20	6.0	24.1	Green
150 x 50	6.0	60.4	Green
180 x 6	6.0	8.69	White
180 x 5	6.0	7.24	Orange
180 x 10	6.0	14.5	Yellow
180 x 16	6.0	23.2	Grey
180 x 12	6.0	17.4	Pink
180 x 20	6.0	29.0	Green
200 x 6	6.0	9.66	White
180 x 25	6.0	36.2	Purple
200 x 8	6.0	12.9	Red
200 x 12	6.0	19.3	Pink
200 x 10	6.0	16.1	Yellow
200 x 16	6.0	25.7	Grey
200 x 25	6.0	40.3	Purple
200 x 20	6.0	32.2	Green
250 x 6	6.0	12.1	White
250 x 10	6.0	20.1	Yellow
250 x 8	6.0	16.1	Red

Equivalent grade of cupro nickel Flat bar

Grade	UNS	Werkstoff Nr.
90/10	C70600	2.0872
70/30	C71500	2.0882

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Copper Nickel Flat Bars Types

ASTM B151 UNS C71500 Flat Rod Dealer in Abu Dhabi, Cupro Nickel Flat Bar Manufacturer in Abu Dhabi, Cupro Nickel Cold Drawn Flat Bar Supplier in Al Ain, Copper Nickel Flat Bars Size Chart, CUNI Flat Bar Price in Ajman, Stockist of Cunifer Flat Rod in Jebel Ali, DIN 2.0872 Flat Rod Exporter in Abu Dhabi, Copper Nickel Flat Rods Supplier in UAE, ASTM B111 Copper Nickel Flat Bar Price List in Dubai, ,UNS C70600 Flat Rod Supplier in Al Ain

Copper Nickel Flat Bars Uses

Copper Nickel Flat Bars are extensively utilized across various industries thanks to their outstanding corrosion resistance, especially in marine settings. They find common use in shipbuilding, offshore oil and gas platforms, desalination plants, and seawater piping systems. Additionally, these bars are employed in heat exchangers, condensers, and power plants due to their thermal conductivity and resistance to biofouling. In the chemical processing sector, they are essential for applications involving corrosive fluids.

Our Products

Other Products

Other Material

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
