Kanish Metals has earned a solid reputation as a reliable manufacturer and supplier of Aluminium 6061 Forgings in Dubai, UAE, providing top-notch products tailored to meet a variety of industrial needs. Aluminium 6061 is a highly adaptable alloy celebrated for its remarkable strength, resistance to corrosion, and excellent machinability. We produce our forgings using cutting-edge technology, ensuring they deliver outstanding performance, durability, and precise dimensions. Thanks to their lightweight nature and impressive mechanical properties, Aluminium 6061 Forgings find applications in numerous sectors, including automotive, aerospace, marine, and construction. At Kanish Metals, we are dedicated to providing premium-grade solutions that adhere to international standards while meeting our customers’ needs with reliability and precision.
Aluminium 6061 Forgings are primarily made up of aluminium, with magnesium and silicon as the key alloying elements. This unique blend offers excellent corrosion resistance, weldability, and toughness. The alloy boasts a tensile strength that ranges from 240 MPa to 310 MPa, along with a yield strength of about 240 MPa, depending on the temper. It also provides great fatigue resistance, good elongation, and hardness levels between 95 and 107 HB. Moreover, Aluminium 6061 maintains stability during heat treatment and showcases exceptional performance in challenging environments, making it a dependable choice for heavy-duty and precision engineering applications.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96061 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 | AA6061 | 3.3211 |
Aluminum 6061 offers excellent strength-to-weight ratio, corrosion resistance, machinability, weldability, and thermal conductivity, making it ideal for custom forgings in aerospace, automotive, and structural applications.
Aluminum 6061 is not ideal for high-temperature forging due to its lower melting point and limited high-temperature strength. It is better suited for structural applications, not extreme heat environments.
Due to their strength, corrosion resistance, and versatility, Aluminium 6061 Forgings are widely utilized across various industries. In aerospace, they are used for aircraft fittings, wings, and structural components. The automotive industry incorporates them into chassis parts, wheels, and engine components, while the marine sector relies on them for boat frames and marine hardware, thanks to their resistance to seawater corrosion. Additionally, these forgings are employed in defense, construction, and oil & gas equipment, as well as in pipelines and machinery where lightweight yet robust materials are crucial for performance and longevity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
