Kanish Metals is a reliable aluminium 5754 forgings manufacturer and supplier in Dubai, UAE, providing top-quality products customized to cater to various industrial requirements. Renowned for the supply of tough and dependable metal components, Kanish Metals guarantees each forging is manufactured applying cutting-edge technology and rigorous quality control measures. Aluminium 5754 is known for its superior corrosion resistance, particularly in saltwater environments, and is best suited for structural use. Being customer-focused with prompt delivery and global compliance, Kanish Metals supplies precision-forged aluminium products to industries including automobile, marine, aerospace, and buildings.
Forgings of Aluminium 5754 consist mainly of aluminium with magnesium as the primary alloying constituent (2.6%–3.6%). This alloy possesses high corrosion resistance, especially in seawater and industrially contaminated atmospheres. Mechanically, it possesses a tensile strength of about 220–330 MPa, while its yield strength is around 130–260 MPa, with the temper determining this. The alloy also exhibits good weldability and moderate-to-high strength, as well as good formability and fatigue resistance. Its mechanical strength allows it to be used in load-bearing structures without excessive weight, which is favorable in strength-to-weight industries.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
Aluminum 5754 has excellent workability, making it easy to forge. Its good formability allows for intricate shapes, but requires careful temperature control to prevent cracking and ensure quality.
Aluminum 5754 offers excellent corrosion resistance, high strength, good weldability, and formability. It's lightweight, resistant to stress corrosion cracking, and performs well in marine and industrial environments.
Aluminium 5754 forgings find widespread usage in the manufacture of industries that involve corrosion and lightweight applications. In the marine industry, they prove suitable for hulls of boats, deck structures, and other components that come into contact with seawater. They are utilized in the automobile sector for structural reinforcements and chassis components because they are strong and possess high impact resistance. In building construction, they find applications in facades, platforms, and other architectural components. They are also used in food processing machinery, chemical storage tanks, and pressure vessels. Their high formability and strength render them appropriate for both dynamic and static loading conditions in various engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
