Kanish Metals has built a solid reputation as a leading manufacturer and supplier of top-quality Nickel Alloy Rectangular Bars in Dubai, UAE. We cater to a variety of industrial sectors with materials that deliver high performance. Our nickel alloy rectangular bars are designed for durability, strength, and outstanding resistance to heat and corrosion. Manufactured to meet international standards, they are perfect for critical applications in chemical processing, power generation, marine, and aerospace industries. At Kanish Metals, we focus on quality, precision, and timely delivery, making us a reliable source for nickel alloy products throughout the UAE and the Middle East’s demanding industrial landscape.
Nickel Alloy Rectangular Bars are mainly made from high-purity nickel (up to 99.6% in grades like Nickel 200), with small amounts of elements like iron, copper, manganese, and silicon added based on the alloy type. These bars boast impressive mechanical properties, featuring tensile strengths between 400 to 600 MPa, along with good yield strength and elongation. They retain toughness and ductility even at high temperatures. Nickel alloys provide exceptional corrosion resistance in both acidic and alkaline environments, as well as excellent thermal and electrical conductivity, making them ideal for a range of structural and functional industrial applications.
| Specifications | ASTM B160 / ASME SB160 |
| Dimension Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Bar Diameter | 3 ~ 800mm | Rectangular Bars | Size: 33 x 30mm to 295 x 1066mm. Thickness: 3.0 to 12.0mm. |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients requirements |
| Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|
| 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Nickel Alloy Rectangular Bars find extensive use in industries where strength, corrosion resistance, and thermal stability are essential. They are commonly used in chemical processing equipment, heat exchangers, pressure vessels, and marine hardware. Additionally, these bars are utilized in electrical systems, battery manufacturing, and power plants due to their superior conductivity and non-magnetic properties. In the aerospace and defense sectors, they are crucial components for engines, brackets, and structural supports. Their ability to endure harsh conditions makes them a go-to choice for various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
