Kanish Metals stands out as a top manufacturer and supplier in Dubai, UAE, specializing in high-quality Stainless Steel 904L Forgings. These products are crafted to offer outstanding corrosion resistance, durability, and strength, even in the toughest industrial settings. Renowned for their resilience against highly acidic conditions and chloride-rich environments, these forgings deliver reliable performance across various sectors, including chemical processing, marine, petrochemical, and oil and gas industries. With its low carbon content and rich alloy composition, Stainless Steel 904L is known for its exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, making it a go-to material for critical applications.
The composition of Stainless Steel 904L Forgings includes significant amounts of nickel, chromium, molybdenum, and copper, which provide remarkable resistance to reducing acids like sulfuric and phosphoric acids. The low carbon content helps prevent carbide precipitation, ensuring excellent weldability and formability. These forgings boast high tensile and yield strength, impressive impact toughness, and outstanding stability under high pressure and elevated temperatures. Their combination of excellent mechanical properties and exceptional corrosion resistance makes them ideal for demanding applications in harsh environments.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | Cu | |
| 904L | min. | – | – | – | – | – | 19.0 | 4.0-5.0 | 23.0 | 1.0 |
| max. | 0.20 | 2.0 | 1.0 | 0.045 | 0.035 | 23.0 | 28.0 | 2.0 | ||
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Yes, Stainless Steel 904L can be forged into custom shapes. Through advanced forging techniques, it can be shaped into various configurations to meet specific design and performance requirements for different applications.
Stainless Steel 904L forgings require minimal maintenance. Regular cleaning with mild detergents, periodic inspections for corrosion, and avoiding high-temperature exposure to chloride-rich environments ensure optimal performance and longevity.
Yes, Stainless Steel 904L forgings can be customized for specific applications. They can be tailored in size, shape, and finish to meet unique requirements, ensuring optimal performance in various industries.
Stainless Steel 904L Forgings find extensive use in industries that require materials capable of withstanding severe corrosive conditions. They are commonly utilized in chemical processing equipment, seawater cooling systems, desalination plants, and marine engineering projects. In the oil and gas industry, they are essential for pumps, valves, flanges, and pipeline components that come into contact with aggressive fluids. Their durability and versatility also make them suitable for the pulp and paper industry, pharmaceutical processing, and power generation plants. With their superior corrosion resistance and strength, Stainless Steel 904L Forgings are a dependable choice for heavy-duty engineering and industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
