Kanish Metals stands out as a top manufacturer and supplier of high-performance stainless steel products in Dubai, UAE. They specialize in premium Stainless Steel 347H Forgings, which are crafted for high-temperature and high-pressure applications. With a strong focus on quality, precision, and reliability, Kanish Metals delivers forged components that adhere to international standards, making them perfect for even the toughest industrial settings. The SS 347H Forgings are designed to provide outstanding mechanical strength along with excellent resistance to corrosion and oxidation. Supported by a talented team and state-of-the-art facilities, Kanish Metals caters to vital sectors like petrochemical, oil & gas, power generation, and aerospace throughout the UAE and beyond.
Stainless Steel 347H Forgings are a type of stabilized austenitic stainless steel alloy that includes Chromium (17–19%), Nickel (9–13%), and Columbium (Niobium) to boost resistance against intergranular corrosion. Tailored for high-temperature applications, 347H features a higher carbon content compared to 347, which enhances its creep resistance and mechanical strength. Typically, this alloy shows a tensile strength of about 75,000 psi, a yield strength of 30,000 psi, and good elongation properties. It maintains its structural integrity and oxidation resistance even at temperatures up to 1000°C (1832°F), making it ideal for extreme thermal cycling and prolonged exposure to high heat.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti | SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Stainless Steel 347H Forgings are perfect for situations that involve high temperatures and corrosive environments. They are commonly found in heat exchangers, boiler tubes, superheaters, and furnace components, and play a crucial role in petrochemical refineries and thermal processing plants. Thanks to their high carbon content, these forgings offer enhanced strength and creep resistance, making them suitable for pressure vessels and piping systems under high-stress conditions. SS 347H Forgings excel in welding applications, ensuring reliability and performance in demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
