Kanish Metals has established itself as a reliable manufacturer and supplier of Stainless Steel 316Ti Forgings in Dubai, UAE. They pride themselves on delivering top-notch products that excel in corrosion resistance, durability, and mechanical strength. The Stainless Steel 316Ti is a titanium-stabilized variant of 316 stainless steel, which means it offers better protection against intergranular corrosion and performs well even at higher temperatures. The forgings made from this material are known for their precision, toughness, and dependability, making them perfect for critical industrial applications. Thanks to their advanced forging techniques, strict quality control, and prompt delivery, Kanish Metals has earned a solid reputation as a trusted supplier of Stainless Steel 316Ti Forgings across various sectors in the region.
These forgings consist of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and trace amounts of titanium, which help stabilize the structure and prevent carbide precipitation during welding or when exposed to high temperatures. They boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. The addition of titanium not only boosts creep strength but also enhances long-term mechanical stability while ensuring excellent resistance to pitting, stress corrosion cracking, and scaling at elevated temperatures.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Yes, Stainless Steel 316Ti can be forged into custom shapes. Its excellent formability and resistance to corrosion make it suitable for creating complex designs required in various industries.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Stainless Steel 316Ti Forgings find their place in industries that demand exceptional corrosion resistance, toughness, and high-temperature strength. They are perfect for applications like chemical processing equipment, heat exchangers, marine uses, flanges, fittings, pressure vessels, and power generation systems. Their ability to resist chloride corrosion makes them ideal for the oil and gas, food processing, and pharmaceutical sectors, where hygiene and reliability are paramount. Additionally, they are utilized in architectural and environmental equipment that requires long-lasting durability. Overall, Stainless Steel 316Ti Forgings offer an outstanding blend of corrosion resistance, mechanical performance, and heat stability, making them a go-to choice for demanding engineering and industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
