Kanish Metals is a well-established Dubai, UAE-based manufacturer and supplier of Stainless Steel 304L forgings renowned for offering high-quality forged parts designed to fulfill numerous industrial standards. With an emphasis on precision, strength, and customer satisfaction, the company supplies products in accordance with international specifications. Kanish Metals is known to maintain a reputation for timely delivery, competitive prices, and fine service. Their 304L stainless steel forgings are relied upon by customers from various industries for their consistency, and Kanish Metals is an ideal collaborator for high-performance stainless steel forging solutions across the UAE and adjacent areas.
304L Stainless Steel is a low-carbon variant of 304 stainless steel, comprising around 18% chromium and 8% nickel with less than 0.03% carbon content. This composition enhances corrosion resistance, particularly after welding operations. It provides mechanical properties like tensile strength of approximately 485 MPa, yield strength of 170 MPa, and 40% elongation with an average hardness of 70 HRB. Stainless Steel 304L has retained strength and toughness even at sub-zero temperatures, which makes it a versatile option for a wide range of industrial applications where corrosion resistance and mechanical strength are crucial.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Post-forging operations for Stainless Steel 304L include heat treatment, machining, surface finishing, and testing to ensure optimal strength, dimension accuracy, and corrosion resistance.
To determine if Stainless Steel 304L forgings meet your needs, review material certifications, perform quality checks, and ensure they meet required mechanical properties and dimensional standards.
After Stainless Steel 304L forgings, slow cooling in air or controlled environments is recommended to prevent cracking and ensure uniform grain structure and mechanical properties.
Stainless Steel 304L forgings find wide application in industries demanding high corrosion resistance and toughness. Some of the common applications are in food processing equipment, storage tanks for chemicals, components for marine applications, and heat exchangers. The good weldability and formability of the material allow it to find application in pharmaceutical and petrochemical equipment, as well as the oil and gas industry. Its tolerance of a broad spectrum of acids and corrosive conditions makes it suitable to be used in valves, flanges, pump components, and structural elements. These forgings are also desirable in architecture and construction where both performance and beauty matter.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
