Kanish Metals stands out as a top manufacturer and supplier of Stainless Steel 316 Forgings in Dubai, UAE. They provide high-quality forged components that are built to last, offering strength and durability even in the toughest environments. With cutting-edge forging techniques and a commitment to international standards, Kanish Metals produces precision-engineered SS 316 forgings for a variety of industries, including marine, chemical processing, food, pharmaceuticals, and oil & gas. Renowned for their timely deliveries and outstanding product performance, the company has earned the trust of clients across the UAE and beyond, supplying dependable stainless steel forging solutions that thrive in both structural and corrosive settings.
Stainless Steel 316 forgings are made up of roughly 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a maximum carbon content of 0.08%. The molybdenum enhances resistance to pitting and crevice corrosion, especially in environments rich in chlorides. SS 316 boasts impressive mechanical properties, featuring a tensile strength of around 515 MPa, yield strength of 205 MPa, and an elongation of 40%. These forgings deliver exceptional toughness, strength, and corrosion resistance, even at high temperatures, making them perfect for critical applications that involve significant mechanical stress and harsh operating conditions.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Yes, Stainless Steel 316 forgings can be shaped into custom forms using precision forging techniques, allowing for a wide range of applications in various industries, including marine and chemical sectors.
The ideal temperature range for forging Stainless Steel 316 is between 2100°F to 2300°F (1149°C to 1260°C), ensuring optimal ductility and minimizing the risk of cracking.
The forging process for Stainless Steel 316 typically takes from a few minutes to several hours, depending on the part's complexity, size, and required finishing.
You’ll find Stainless Steel 316 forgings in a variety of applications that demand high strength, excellent corrosion resistance, and reliable performance. Common uses include valve bodies, pump components, flanges, pipe fittings, shafts, and fasteners in marine, chemical, and petrochemical sectors. They’re also essential in pharmaceutical and food processing equipment, where hygiene and corrosion resistance are paramount. Thanks to their ability to resist chlorides and acidic environments, SS 316 forgings are particularly well-suited for offshore structures and coastal installations. Their durability and capacity to handle high pressures and temperatures make them ideal for both demanding and critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
