Kanish Metals stands out as a top-notch manufacturer and supplier of high-quality Stainless Steel 304 Forgings right here in Dubai, UAE. We’ve built a solid reputation for excellence, focusing on delivering durable and precision-engineered forgings that align with international standards. Our products are well-known for their outstanding corrosion resistance, strength, and impressive performance even in the toughest environments. We serve a variety of industries, including oil & gas, construction, marine, and petrochemicals, providing custom forging solutions tailored to meet our clients’ specific needs. With cutting-edge technology and a skilled team behind us, Kanish Metals guarantees timely delivery and competitive pricing, making us a reliable partner in the stainless steel market.
Stainless Steel 304 is an austenitic alloy that consists of about 18% chromium and 8% nickel, along with trace amounts of carbon, manganese, silicon, phosphorus, and sulfur. This unique blend gives it remarkable resistance to corrosion and oxidation. On the mechanical side, SS 304 boasts a minimum tensile strength of 515 MPa and a yield strength of at least 205 MPa, with an elongation of 40% and a maximum Brinell hardness of 201 HB. These characteristics make it an excellent choice for applications that demand strength, ductility, and durability in both high and low-temperature settings.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| (UNS) | Tensile Strength (MPa) ≥ | Yield Strength ≥ (MPa) at 0.2% Offset | Elongation in 50 mm (%, ≥) | Reduction of Area, %, ≥ | Brinell Hardness (HBW) ≤ | Rockwell Hardness (HRBW) ≤ | Product | Condition |
| 304 (UNS S30400) | 515 | 205 | 40 | – | 201 | 92 | Plate, Sheet, and Strip | – |
| 515 | 205 | 40 | 50 | – | – | Bars and Shapes | Hot finished | |
| 620 | 310 | 30 | 40 | – | – | Cold finished, Dia ≤ 12.7mm | ||
| 515 | 205 | 30 | 40 | – | – | Cold finished, Dia. > 12.7mm |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
Yes, Stainless Steel 304 forgings can be customized into various shapes through precise forging techniques, offering flexibility for different industrial applications and design requirements.
The ideal temperature range for forging Stainless Steel 304 is between 2100°F to 2300°F (1149°C to 1260°C) to ensure optimal malleability and strength.
Stainless Steel 304 Forgings are widely utilized across various industries due to their exceptional corrosion resistance, strength, and ease of fabrication. In construction, they play a vital role as key components in structural supports and frameworks. The food and beverage industry counts on SS 304 for hygienic processing equipment, thanks to its non-reactive properties. It’s also crucial in the marine and chemical sectors for parts that face harsh conditions. Moreover, these forgings find their place in pharmaceutical manufacturing, automotive components, heat exchangers, valves, and flanges, ensuring long-term reliability and performance in demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
