Kanish Metals, located in Dubai, UAE, is a reliable manufacturer and supplier of Stainless Steel 316L Forgings, providing high-quality forged components tailored to meet the demands of various industries. With a reputation for precision manufacturing, quality assurance, and adherence to international standards, Kanish Metals delivers SS 316L forgings that boast exceptional corrosion resistance and mechanical strength. These forgings are perfect for applications that require outstanding weldability and cleanliness. Catering to sectors such as marine, pharmaceutical, food processing, and chemicals, Kanish Metals is known for its reliability, quick delivery, and consistent forging solutions that thrive in harsh and corrosive environments.
Stainless Steel 316L forgings consist of 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a maximum carbon content of 0.03%. The lower carbon content significantly improves resistance to intergranular corrosion after welding. SS 316L offers a tensile strength of around 485 MPa, a yield strength of 170 MPa, and an elongation of about 40%. These forgings excel in corrosion resistance, particularly in environments rich in chlorides or acids. With their remarkable ductility, weldability, and toughness, SS 316L forgings are ideal for critical applications where long-lasting durability and structural integrity are paramount.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Yes, Stainless Steel 316L can be forged into custom shapes, offering flexibility for various applications. Its excellent machinability allows precise fabrication.
Stainless Steel 316L Forgings require minimal maintenance, primarily periodic cleaning to prevent corrosion buildup. Regular inspections ensure long-term performance and durability.
Stainless Steel 316L Forgings may have limited strength at very high temperatures and can be more expensive than other grades. It may also be susceptible to localized corrosion in certain environments.
Industries that prioritize hygiene, corrosion resistance, and mechanical reliability frequently utilize Stainless Steel 316L forgings. Common applications include forged valves, flanges, fittings, pump housings, fasteners, and shafts across marine, pharmaceutical, chemical, and food processing sectors. Their ability to resist pitting, crevice corrosion, and chemical exposure makes them particularly suitable for coastal environments, process equipment, and sanitary systems. Additionally, SS 316L forgings are favored for heat exchangers, pressure vessels, and welded structures due to their low carbon content and excellent weldability. Their strength and reliability make them a top choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
