Kanish Metals is a prominent manufacturer and supplier of titanium grade 12 rods and bars in Dubai, UAE, offering high-quality titanium rods and bars for industries which require superior corrosion resistance and strength. With attention to precision manufacturing and conformance to international standards, Kanish Metals provides titanium grade 12 products that reliably perform in aggressive chemical and marine environments. This alloy is distinguished by its superior resistance to corrosion in mildly reducing and oxidizing conditions. Used in industries including chemical process, power generation, and marine construction, Kanish Metals offers reliable delivery and consistent product performance.
Titanium grade 12 rods and bars contain titanium alloyed with 0.8% nickel and 0.3% molybdenum, which increases corrosion resistance and strength. The alloy has the formability of commercially pure titanium and also offers enhanced resistance to crevice corrosion and stress corrosion cracking. The grade 12 titanium has a tensile strength of around 500–600 MPa and yield strength of around 400–450 MPa. It also offers good weldability, average ductility, and superb performance in hot acid or chloride solution environments. These mechanical and chemical features make grade 12 the best for challenging industrial applications with corrosive operating conditions.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 12 | 3.7105 | R53400 |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 9 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Grade 12 Titanium Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 12 offers excellent resistance to corrosion, especially in oxidizing and mildly reducing environments, and is highly durable in seawater and chemical processing conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@kanishmetals.ae
Yes, Titanium Grade 12 exhibits remarkable high-temperature resistance, making it suitable for use in power generation and industrial processes that involve elevated temperatures.
Titanium grade 12 rod and bars are used extensively in industries that need tough, corrosion-resistant materials under harsh environmental conditions. In chemical processing, they are best applied in heat exchangers, evaporators, and piping systems that deal with hot acidic or chloride-containing solutions. In the marine industry, grade 12 is excellent when it comes to saltwater and offshore structures. It is also applied in power generation plants, particularly in condenser tubing and cooling systems. Due to its outstanding corrosion resistance and its ease of manufacture, titanium grade 12 is ideal for use in oil and gas, desalination, and pollution control applications where long life and strength are of utmost importance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
