Kanish Metals, located in Dubai, UAE, stands out as a top manufacturer and supplier of high-quality stainless steel products, including Stainless Steel 904L square bars and rods. With a strong commitment to quality and customer satisfaction, Kanish Metals delivers 904L square bars and rods that excel in resisting corrosion, especially in harsh chemical and marine settings. These products find their way into various industries, such as chemical processing, marine, and pharmaceuticals. By prioritizing precision and timely delivery, Kanish Metals guarantees dependable, high-performance stainless steel solutions for clients both in the UAE and around the globe.
Stainless Steel 904L square bars and rods are primarily made up of iron, chromium (19-23%), nickel (24-26%), molybdenum (4-5%), and copper (1-2%). The elevated levels of nickel and molybdenum give these materials outstanding resistance to corrosion in acidic and chloride-heavy environments. They boast impressive mechanical properties, including tensile strength reaching up to 1000 MPa, strong resistance to pitting and crevice corrosion, and good ductility. Known for their remarkable formability and resistance to stress corrosion cracking, 904L square bars and rods are perfect for use in both acidic and alkaline conditions.
| Specifications | : | ASTM A276, ASME SA276 / ASTM A479 ASME SA479 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 904L Square Bars | : | Outside Diameter in the range of 4mm to 500mm |
| SS 904L Square Bars | : | 18mm ” 47mm (11/16″ to 1-3/4″) |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN | EURONORM NAME |
| SS 904L | 1.4539 | N08904 | – | 904S13 | – | X1NiCrMoCuN25-20-5 |
| SQUARES | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, we provide stainless steel 904L square bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@kanishmetals.ae
Stainless Steel 904L Square Rods are known for their exceptional corrosion resistance, high strength, and excellent weldability, making them ideal for harsh environments. They also exhibit good formability, durability, and resistance to pitting and crevice corrosion.
Yes, Stainless Steel 904L Square Bars can be recycled after use. Their high nickel and chromium content make them valuable for recycling, reducing waste and conserving resources.
Stainless Steel 904L square bars and rods are extensively utilized in industries that demand materials with exceptional corrosion resistance and durability in tough environments. In chemical processing facilities, they are essential for creating reactors, heat exchangers, and piping systems that come into contact with aggressive chemicals. In marine settings, 904L square bars and rods are employed in components like propeller shafts and offshore equipment, providing reliable resistance to seawater corrosion. Furthermore, these bars and rods are also crucial in the pharmaceutical and food processing sectors, where their corrosion resistance and durability are vital for maintaining the integrity of equipment in challenging operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
