Kanish Metals, based in Dubai, UAE, has made a name for itself as a top-notch manufacturer and supplier of premium stainless steel products, including Stainless Steel 416 square bars and rods. Known for their commitment to precision and quality, Kanish Metals provides 416 square bars and rods that boast excellent machinability, impressive corrosion resistance, and remarkable strength. These products are perfect for industries that need materials that strike a balance between hardness and ease of fabrication. With a focus on delivering customized stainless steel solutions promptly, Kanish Metals has earned a reputation as a reliable supplier of 416 square bars and rods, both in the UAE and around the globe.
Stainless Steel 416 square bars and rods are primarily made up of iron, chromium (12-14%), and carbon (0.15-0.40%), along with trace amounts of manganese, silicon, and sulfur. The chromium content ensures good corrosion resistance, while the higher carbon content enhances the material’s machinability and hardness. In terms of mechanical properties, these bars can achieve a tensile strength of up to 850 MPa, a yield strength of about 450 MPa, and a hardness rating of Rockwell C 35-40. Stainless Steel 416 is particularly prized for its ease of machining, making it a go-to choice for precision applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 416 | 1.4005 | S41600 | SUS 416 | 416S21 | – | – | X12CrS13 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 416 square bars are susceptible to galvanic corrosion when in contact with more noble metals, such as copper or brass, in the presence of an electrolyte. Proper insulation and material selection can help mitigate this risk.
Yes, we provide 416 Stainless Steel Square Bars and Rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@kanishmetals.ae
Stainless Steel 416 square rods are available in various sizes, typically ranging from 1/4" to 6" in width. They come in finishes like cold-finished, hot-rolled, or polished, depending on the application requirements.
Stainless Steel 416 square bars and rods are commonly found in industries where machinability, strength, and corrosion resistance are crucial. In the automotive sector, they are used to manufacture components such as shafts, gears, and valve parts. In aerospace, 416 square bars and rods are essential for aircraft components that demand high strength and wear resistance. These bars also play a vital role in producing fasteners, pumps, and hydraulic systems, providing a great balance of hardness and mild corrosion resistance. Furthermore, they are utilized in medical and industrial machinery parts that require durability and ease of fabrication.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
