Kanish Metals has built a solid reputation as a reliable manufacturer and supplier of Stainless Steel 317 Square Bars and Rods in Dubai, UAE. They pride themselves on delivering top-notch products that are crafted for exceptional corrosion resistance, mechanical strength, and long-lasting durability. Stainless Steel 317 is a special type of austenitic stainless steel enriched with molybdenum, which gives it remarkable resistance to pitting, crevice corrosion, and tough chemical environments. The square bars and rods made from this grade are designed to provide precision, durability, and reliability, making them perfect for critical industrial applications. Thanks to their advanced manufacturing techniques, rigorous quality control, and prompt delivery, Kanish Metals has become a trusted supplier of Stainless Steel 317 Square Bars and Rods across various industries in the region.
These square bars and rods consist of 18–20% chromium, 11–13% nickel, and 3–4% molybdenum, which significantly boosts their corrosion resistance and mechanical properties. They boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. The molybdenum content plays a key role in providing excellent resistance to oxidation, stress corrosion cracking, and high-temperature scaling. With their outstanding mechanical stability, toughness, and durability, these square bars and rods are well-suited for demanding industrial applications.
Stainless Steel 317 Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4449 | S31700 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317 square bars can be welded using conventional welding methods. However, pre-heating and post-weld heat treatment may be required to avoid cracking.
Yes, Stainless Steel 317 square rods can be heat-treated, typically through solution annealing. However, they are not hardenable by heat treatment like some other stainless steels.
Stainless Steel 317 Square Bars offer excellent corrosion resistance, particularly against chlorides and acids, along with high strength and durability. They are widely used in chemical, petrochemical, and food processing industries.
Stainless Steel 317 Square Bars and Rods find their place in industries that require high levels of corrosion resistance, mechanical strength, and dimensional stability. They are perfect for use in chemical processing equipment, heat exchangers, marine components, pump shafts, valve bodies, and applications in petrochemical plants. Their impressive resistance to harsh environments makes them ideal for the oil and gas, power generation, and food processing sectors. Moreover, they are also utilized in pharmaceutical and medical equipment, where hygiene and corrosion resistance are paramount. Overall, Stainless Steel 317 Square Bars and Rods offer a dependable mix of durability, strength, and resilience against challenging environmental conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
