Kanish Metals stands out as a top manufacturer and supplier of Stainless Steel 316L Square Bars and Rods in Dubai, UAE. They’re known for delivering high-quality products that boast impressive corrosion resistance, mechanical strength, and long-lasting durability. Stainless Steel 316L is a low-carbon, molybdenum-enriched austenitic stainless steel grade that excels in resisting pitting, crevice corrosion, and harsh chemical environments. The square bars and rods made from this material guarantee precision, reliability, and consistent performance, even in the most demanding industrial settings. Thanks to their state-of-the-art manufacturing facilities, strict quality control, and prompt delivery, Kanish Metals has earned a solid reputation as a trusted supplier of Stainless Steel 316L Square Bars and Rods across various industries in the region.
These square bars and rods are made up of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which significantly enhance their corrosion resistance and strength. They offer a tensile strength of around 485–505 MPa, yield strength of 170–205 MPa, and an elongation of 40%. The low-carbon content helps reduce carbide precipitation during welding, ensuring excellent corrosion resistance, toughness, and long-term stability. These features make Stainless Steel 316L Square Bars and Rods perfect for high-performance and corrosion-sensitive applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316l | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 Min | 170 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316l | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 316L Square Bars are highly corrosion-resistant, especially to pitting and crevice corrosion in chloride environments. This makes them ideal for marine and chemical applications.
Stainless Steel 316L square bars are generally non-magnetic in their annealed state. However, they may exhibit slight magnetism when cold worked.
Yes, Stainless Steel 316L square bars are suitable for heat exchangers due to their excellent corrosion resistance, high-temperature stability, and good weldability. They are ideal for applications in corrosive and high-temperature environments.
You’ll find Stainless Steel 316L Square Bars and Rods widely used in industries that demand exceptional corrosion resistance, mechanical performance, and dimensional stability. They’re ideal for chemical processing equipment, heat exchangers, pump shafts, valve bodies, marine applications, and desalination plants. Their ability to resist chloride-induced corrosion makes them particularly suitable for the oil and gas, food processing, and pharmaceutical industries, where hygiene and reliability are paramount. Additionally, they’re utilized in power generation and architectural projects. Overall, Stainless Steel 316L Square Bars and Rods offer a reliable blend of durability, strength, and performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
