Kanish Metals has made a name for itself as a leading manufacturer and supplier of Stainless Steel 317L Square Bars and Rods, proudly based in Dubai, UAE. We take pride in offering top-notch stainless steel products that are built to thrive in tough and corrosive environments. Our SS 317L square bars and rods are crafted with precision and meet international quality standards, guaranteeing exceptional durability, strength, and resistance to chemical attacks. We cater to a variety of industries, including chemical processing, marine, and pharmaceuticals, providing tailored solutions to fit a wide range of application needs. Our commitment to quality, timely delivery, and outstanding customer service extends throughout the UAE and beyond.
Stainless Steel 317L is a low-carbon, high-molybdenum austenitic stainless steel that contains about 18–20% chromium, 11–15% nickel, and 3–4% molybdenum, along with low carbon content for improved weldability. This unique composition gives it remarkable resistance to chemical corrosion, particularly in acidic and chloride-rich settings. Its mechanical properties boast a minimum tensile strength of 515 MPa, yield strength of 205 MPa, elongation of 35%, and a maximum Brinell hardness of 217 HB. These features make SS 317L square bars and rods perfect for high-performance applications in challenging operating conditions.
Stainless Steel 317L Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 15.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4438 | S31703 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317L square bars and rods can be recycled after use. They retain their properties and can be repurposed for new applications, making them highly sustainable.
To ensure the quality of Stainless Steel 317L square rods, source them from reputable suppliers and conduct material tests such as chemical composition and mechanical properties. Additionally, check for compliance with relevant industry standards and certifications.
Yes, Stainless Steel 317L square bars can be used for underground applications due to their excellent corrosion resistance, particularly in environments with high moisture or chloride exposure. Their durability ensures long-lasting performance in such conditions.
Stainless Steel 317L Square Bars and Rods are extensively used in industries that require exceptional corrosion resistance and high strength. In the chemical and petrochemical fields, they are essential for creating reactors, heat exchangers, and process piping that face acidic environments. The marine industry relies on them for structural components exposed to seawater. They are also well-suited for pulp and paper plants, food processing equipment, and flue gas scrubbers due to their resistance to chlorides and sulfates. Their low carbon content makes them ideal for welded structures that need to endure long service lives and maintain durability in harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
