Kanish Metals is a reputable manufacturer and supplier of Stainless Steel 310S Square Bars and Rods, proudly based in Dubai, UAE. With a strong commitment to quality, precision, and customer satisfaction, Kanish Metals delivers top-notch SS 310S products that adhere to international standards. These square bars and rods are expertly crafted for high-temperature and corrosive environments, making them perfect for a wide range of industrial applications. Equipped with cutting-edge facilities and a focus on reliability, Kanish Metals caters to industries like petrochemical, thermal processing, power generation, and furnace manufacturing, both in the UAE and around the globe.
The Stainless Steel 310S square bars and rods are made up of about 24–26% chromium, 19–22% nickel, and a maximum of 0.08% carbon. This low-carbon version of SS 310 enhances weldability while maintaining excellent resistance to oxidation and heat. It boasts a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. This alloy performs exceptionally well in high-temperature settings, enduring up to 1100°C. It also offers good creep resistance and structural integrity, making it a fantastic choice for demanding thermal and mechanical applications in industrial settings.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 310S | 0.08 max | 24.0 – 26.0 | 2.00 max | 19.0 – 22.0 | 0.045 max. | 0.03 max. | 1.50 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 310 | 8 | 1400 ℃ | 515 MPa | 205 | 40 – 50 | 160 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 310S | 1.4845 | S31008 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 310S Square Bars can be customized in size and length according to specific requirements. They offer flexibility to meet various industry needs.
Stainless Steel 310S Square Rods perform exceptionally well in high-temperature environments due to their excellent oxidation and heat resistance. They can withstand temperatures up to 1100°C (2012°F) in intermittent service.
Stainless Steel 310S Square Bars are not typically recommended for underground applications due to their susceptibility to corrosion in soil and moisture. They are better suited for high-temperature and oxidation-resistant environments.
Stainless Steel 310S square bars and rods are widely utilized in industries that need materials resistant to high temperatures and corrosion. You’ll find them in applications like heat treatment equipment, furnace components, kiln linings, combustion chambers, and radiant tubes. They’re also essential in chemical processing plants, refineries, power stations, and exhaust systems where high heat and corrosive gases are a regular occurrence. SS 310S is particularly suited for welded structures and components that experience thermal cycling. Its durability, formability, and resistance to scaling and oxidation make it a dependable option for both structural and mechanical engineering needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
