Kanish Metals has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 316 Square Bars and Rods in Dubai, UAE. Their products are celebrated for top-notch quality, boasting impressive corrosion resistance, durability, and strength. Stainless Steel 316 is a special type of austenitic stainless steel that contains molybdenum, giving it an edge over 304 stainless steel when it comes to resisting pitting, crevice corrosion, and harsh chloride environments. The square bars and rods crafted from this grade are made with precision and toughness, ensuring they perform well in demanding industrial and engineering settings. Thanks to cutting-edge manufacturing techniques, rigorous quality control, and prompt delivery, Kanish Metals has established itself as a trusted supplier of Stainless Steel 316 Square Bars and Rods across various industries.
These square bars and rods consist of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which significantly boost their corrosion resistance and mechanical properties. They offer a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. The molybdenum content enhances their ability to withstand chloride attacks, oxidation, and scaling at high temperatures, all while maintaining excellent toughness and dimensional stability.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 316 square bars are resistant to galvanic corrosion when used in environments with similar metals. However, when coupled with dissimilar metals, they can be susceptible to galvanic corrosion if exposed to electrolytes.
Stainless Steel 316 square rods are available in various sizes ranging from 1/8" to 6" or more, depending on the supplier. They are typically offered in finishes such as mill, polished, or brushed, based on customer requirements.
Yes, Stainless Steel 316 square bars are highly resistant to corrosion, making them suitable for underground applications. Their durability and resistance to rust make them ideal for use in harsh environments.
Stainless Steel 316 Square Bars and Rods find their place in industries where strength, corrosion resistance, and durability are paramount. They are perfect for marine equipment, pump shafts, valve components, chemical processing systems, heat exchangers, and desalination plants. Their outstanding resistance to chlorides makes them particularly valuable in the oil and gas, pharmaceutical, and food processing sectors, where hygiene and reliability are crucial. Additionally, they are utilized in power generation and architectural structures that demand long-lasting performance. With their dependable combination of durability, corrosion resistance, and mechanical strength, Stainless Steel 316 Square Bars and Rods are an excellent choice for a wide range of applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
