Kanish Metals stands out as a reliable manufacturer and supplier of Incoloy 925 Forgings, proudly based in Dubai, UAE. They specialize in providing top-notch alloy solutions tailored for demanding industrial applications. With a strong emphasis on quality, precision engineering, and timely delivery, Kanish Metals serves a variety of sectors, including oil & gas, marine, aerospace, and chemical processing. Their state-of-the-art forging facilities and dedication to international standards ensure that every product they deliver boasts exceptional performance and durability. Clients throughout the UAE and beyond trust Kanish Metals for high-strength, corrosion-resistant forgings that excel in challenging service environments.
Incoloy 925 Forgings are made up of nickel (42–46%), chromium (19.5–22.5%), iron (the balance), molybdenum (2.5–3.5%), copper (1.5–3%), titanium (1.9–2.4%), along with trace amounts of aluminum and niobium. This distinctive composition provides outstanding resistance to sulfide stress cracking and corrosion fatigue. On the mechanical side, the alloy showcases impressive tensile strength (~760 MPa), yield strength (~517 MPa), and good elongation (~25%). These characteristics remain intact even under high pressure and temperature conditions. The alloy’s strength is further boosted through age hardening, making it particularly suitable for harsh oilfield and marine environments.
Specifications ASTM B637 / ASME SB637
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni% | Cr% | Fe% | Mo% | Cu% | Ti% | Al% | Mn% | Si% | Nb% | C% | S% |
| Incoloy 925 | 42.0-46.0 | 19.5-22.5 | Min 22 | 2.5-3.5 | 1.5-3.0 | 1.9-2.4 | 0.1-0.5 | Max 1.0 | Max 0.5 | Max 0.5 | Max 0.03 | Max 0.03 |
| UNS | Heat Treatment | Tensile Strength, min, psi (MPa) | Yield Strength (0.2 % offset), min, psi (MPa) | Elongation in 2 in. (50 mm) or 4D, min, % | Reduction of Area, min, % | Brinell or (Rockwell C) Hardness |
| ASTM B637 UNS N09925 | solution + precipitation harden | 140 000 (965) | 105 000 (724) / 110 000 (758) | 18 | 25 | 346 max (38, Rc max) |
| STANDARD | UNS | WNR. |
| Alloy 925 | N09925 | – |
Incoloy 925 Forgings find extensive application in the oil & gas industry for components like tubing hangers, valves, packers, and downhole equipment, thanks to their remarkable resistance to sulfide stress cracking and corrosion. They are especially well-suited for offshore and sour gas environments where strength and resistance to chloride stress corrosion are vital. In the marine and chemical processing sectors, they are utilized in heat exchangers, fasteners, pump shafts, and flanges that come into contact with aggressive media. Their mechanical strength, corrosion resistance, and thermal stability make them the go-to choice for high-pressure, high-temperature service
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
