Kanish Metals stands out as a reliable manufacturer and supplier based in Dubai, UAE, specializing in top-notch Stainless Steel 420 Bars and Rods. These products are well-known for their impressive hardness, strength, and wear resistance. As a martensitic stainless steel, Stainless Steel 420 can be hardened through heat treatment, making it perfect for applications that require durability and toughness. Additionally, these bars and rods offer moderate corrosion resistance in mild environments, making them versatile for various industrial uses. With a focus on precision manufacturing, Kanish Metals guarantees products that excel in both performance and reliability.
The composition of Stainless Steel 420 Bars and Rods includes chromium with a higher carbon content, which contributes to their exceptional hardness, edge retention, and mechanical strength. They boast high tensile and yield strength, along with good impact resistance and wear resistance. With the right heat treatment, their hardness can be significantly improved while still maintaining toughness. While their corrosion resistance may not match that of austenitic grades, Stainless Steel 420 performs admirably in less corrosive and mildly acidic environments, ensuring a long service life across a range of industrial applications.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 420 (UNS S42000) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 420 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 420 Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | |
| 420 | min. | – | – | – | – | – | 12.0 |
| max. | 0.15 | 1.0 | 1.00 | 0.04 | 0.03 | 14.0 | |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| 420 | 95,000 | 25 | 50,000 | 175 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 420 | 1.4021 | S42000 | SUS 420 J1 | 420S29 | – | – | FeMi35Cr20Cu4Mo2 |
Stainless Steel 420 Bars and Rods are known for their excellent hardness, corrosion resistance, and wear resistance. They are a high-carbon steel that can be heat-treated for maximum hardness and are ideal for applications that require strength and durability, such as cutlery, surgical instruments, and valve parts.
Stainless Steel 420 has higher carbon content compared to other grades like 304 or 316, which allows it to be hardened through heat treatment. This makes it particularly suitable for applications that demand high strength, hardness, and wear resistance, although it may not offer the same corrosion resistance as other austenitic grades.
These Stainless Steel 420 Bars and Rods find extensive use in industries that prioritize hardness, durability, and wear resistance. They’re commonly utilized in the manufacturing of surgical instruments, cutlery, pump shafts, valves, molds, and various mechanical components. Their hardening capability makes them particularly well-suited for tooling applications and precision parts in the automotive and aerospace industries. Furthermore, they are also employed in industrial machinery, gears, and bearings where strength and wear resistance are crucial. When it comes to applications that demand both strength and toughness, Stainless Steel 420 Bars and Rods are a dependable choice.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
