Kanish Metals stands out as a top manufacturer and supplier of Stainless Steel 316L Bars and Rods, proudly based in Dubai, UAE. They provide high-quality stainless steel solutions tailored to meet the rigorous demands of various industries. Renowned for their precision engineering, commitment to quality, and a customer-first mindset, Kanish Metals ensures that their SS 316L products meet international standards. With remarkable corrosion resistance and excellent weldability, 316L bars and rods are perfect for use in chemical, marine, pharmaceutical, and food sectors. Kanish Metals has earned a reputation for delivering durable, high-performance stainless steel products designed to endure harsh and corrosive environments.
Stainless Steel 316L bars and rods are low-carbon versions of SS 316, containing about 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a maximum of 0.03% carbon. This lower carbon content enhances weldability and reduces the risk of carbide precipitation during welding. SS 316L is known for its outstanding corrosion resistance, especially against chlorides and acidic environments. Its mechanical properties include a tensile strength of around 485 MPa, yield strength of 170 MPa, and an elongation of 40%. This alloy maintains both strength and ductility while effectively resisting pitting, crevice corrosion, and stress corrosion cracking in aggressive settings.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 316L (UNS S31603) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316L Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 316L Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L contains molybdenum, which enhances resistance to chloride-induced pitting and corrosion, making it highly suitable for marine and coastal applications.
Yes, the low carbon content in 316L minimizes carbide precipitation during welding, ensuring excellent corrosion resistance even in heat-affected zones.
You’ll find Stainless Steel 316L bars and rods widely used in industries that demand exceptional corrosion resistance and cleanliness. Common applications include marine components, chemical storage tanks, pharmaceutical processing equipment, food-grade machinery, and heat exchangers. Its low carbon content makes it particularly suitable for welded structures exposed to corrosive conditions. SS 316L is also found in medical devices, pulp and paper mills, and wastewater treatment systems. Thanks to its non-reactive nature and resistance to chloride-induced corrosion, it’s an excellent choice for coastal and submerged structures. The alloy’s durability and hygiene make it a go-to option for many applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
