Kanish Metals is a top-grade manufacturer and supplier company in Dubai, UAE, providing premium-quality Stainless Steel 347H Forgings for businesses that require high performance at harsh conditions. Designed with care and compliance with international standards, these forgings are acclaimed for their strength, longevity, and corrosion resistance. Stainless Steel 347H is a high-carbon stabilized austenitic stainless steel that has been developed to offer outstanding high-temperature strength and resistance against intergranular corrosion. With quality, punctual delivery, and customer satisfaction in mind, Kanish Metals provides dependable stainless steel solutions for demanding applications.
Stainless Steel 347H Forgings contain chromium (17–20%) and nickel (9–13%) with increased carbon content over SS 347, adding increased creep strength and stress rupture resistance. Columbium and tantalum stabilize these forgings for effective carbide precipitation resistance when exposed to high temperatures over long periods. SS 347H Forgings have mechanical properties of high tensile strength, superior toughness, good hardness, and metallurgical stability under maximum heat and stress conditions, rendering them for use in harsh industrial conditions.
Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Specification : ASTM A276, A479 / ASME SA276, SA479
Hex Bars : 18mm – 57mm (11/16″ to 2-3/4″)
Square Bars : 18mm – 47mm (11/16″ to 1-3/4″)
Round Bars : Outside Diameter in the range of 4mm to 500mm
Bright Bars : Outside Diameter in the range of 4mm to 100mm
Length : 1 to 6 Meters, Custom Cut Lengths
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle Etc.
|
C |
Ni |
Mn |
P |
S |
Si |
Cr |
Mo |
|
|---|---|---|---|---|---|---|---|---|
|
MIN |
0.040 |
10.000 |
– |
– |
– |
– |
16.000 |
2.000 |
|
MAX |
0.100 |
14.000 |
2.000 |
0.040 |
0.030 |
1.000 |
18.000 |
3.000 |
|
Yield Strength
0.2% Proof
(MPa) |
Tensile strength
(MPa)
|
Elongation
(% in 50mm) |
Hardness (HRB) | |
|---|---|---|---|---|
|
MIN |
170 |
485 |
40.00 |
|
|
MAX |
95 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | BS | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 08Ch17N13M2T | 320S31 | Z6CNDT17‐12 | X6CrNiMoTi17-12-2 |
Stainless Steel 316Ti is stabilized with titanium, enhancing its resistance to intergranular corrosion, especially in high-temperature environments, making it more durable than standard 316 stainless steel.
Yes, these bars and rods are specifically designed for high-temperature applications, offering excellent strength and resistance to oxidation and corrosion under elevated thermal conditions.
Stainless Steel 347H Forgings have extensive applications in petrochemical, chemical process, oil, gas, power generation, and aerospace industries. They find applications in boiler equipment, furnace equipment, pressure vessels, heat exchangers, superheater tubes, and high-temperature, high-pressure piping systems. Their excellent resistance to creep and stress rupture provides them as the best material for use in refineries as well as welded construction exposed to thermal cycling. Moreover, they are employed in food processing equipment, pharmaceutical equipment, and other areas where durable strength and corrosion protection are needed. SS 347H Forgings provide consistent performance and reliability in aggressive service conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
