Dubai-based Kanish Metals is a reliable producer and supplier of high-quality metal items catering to various industries globally. Among its vast product line, Aluminium 5052 rods and bars are prominent for their superior corrosion resistance, toughness, and weldability. Established performance in marine, automotive, and aviation industries makes this alloy precious due to its strength of structure and flawless formability. Kanish Metals is dedicated to providing only the best-quality aluminium solutions, supported by years of market experience and sophisticated manufacturing practices. Providing competitive rates, prompt delivery, and tailored solutions, the company guarantees total satisfaction for small as well as large-sized projects
5052 aluminium bars and rods consist of about 97.25% aluminium, 2.5% magnesium, and 0.25% chromium, with traces of manganese, silicon, iron, and copper. This alloy offers excellent corrosion resistance, especially in marine and industrial atmospheres. The mechanical properties of the alloy are tensile strength of 210–260 MPa, yield strength of approximately 125 MPa, and elongation of 12–20%, and it provides a balance of strength and ductility. With its good weldability, formability, and moderate strength, Aluminium 5052 is an industry favorite where durability and resistance to severe environments are required.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg2,5 | AG2,5C | 3.3523 | A95052 | AlMg2,5 | 5052 | AlMg2,5 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5052 bars can be welded. They offer good weldability using techniques like TIG or MIG welding, making them suitable for a variety of applications in marine and structural industries.
Consider proper handling to prevent surface damage, use appropriate welding techniques, ensure corrosion protection for harsh environments, choose compatible fasteners, and account for temperature fluctuations during installation for optimal performance.
Yes, Aluminium 5052 bars and rods can be used for structural applications due to their excellent corrosion resistance, high strength, and formability, making them suitable for marine, automotive, and industrial uses.
Aluminium 5052 bars and rods find extensive application and are greatly versatile because of their corrosion resistance, strength, and flexibility. They are utilized in the marine sector for the hulls of boats, fuel tanks, and shipbuilding parts that require endurance operation in seawater environments. They find use in the automobile industry for fuel tanks, bumpers, and chassis components where strength and light weight are paramount. In the aerospace industry, 5052 is employed in superstructures, wings, and structural parts that need strength and durability. Outside transportation, the alloy is also applied in heat exchangers, pressure vessels, electrical enclosures, and architectural structures, providing superior weldability and durability in extreme conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
