Kanish Metals stands out as a top manufacturer and supplier of Aluminium 5005 Bars and Rods, catering to both industrial and commercial clients across Dubai, the UAE, and the broader GCC region. Renowned for its impressive corrosion resistance, weldability, and attractive finish, Aluminium 5005 is perfect for architectural and structural uses. Our bars and rods are crafted using cutting-edge processes, guaranteeing precise dimensions and reliable mechanical properties. At Kanish Metals, we focus on quality, prompt delivery, and ensuring our customers are happy. Whether you need decorative panels or industrial assemblies, our Aluminium 5005 products meet international standards and are trusted across various industries for their performance and dependability.
Aluminium 5005 is a non-heat-treatable alloy primarily made up of aluminium (~98.6%), with magnesium (0.5–1.1%) as the main alloying element. It also includes trace amounts of iron, silicon, copper, and chromium. This alloy is known for its outstanding corrosion resistance, especially in marine and industrial environments. Its mechanical properties feature a tensile strength ranging from 170–230 MPa and a yield strength of about 110–190 MPa, depending on the temper. With a Brinell hardness of 45–65 HB, it offers excellent workability, surface finish, and moderate strength, making it ideal for applications that require both form and function.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Others Each | Others Total |
| 5005 | Bal | 0.30 max | 0.70 max | 0.20 max | 0.20 max | 0.10 max | 0.50 / 1.10 | 0.25 max | 0.05 max | 0.15 max |
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm (%) | |||
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6mm | ||||
| 5005 | 0 | 95-145 | – | 18 | 20 | 21 | 22 |
| 5005 | H12 | 125-170 | 80 | 4 | 5 | 6 | 8 |
| 5005 | H14 | 145-185 | 100 | 3 | 3 | 5 | 6 |
| 5005 | H18 | 185 min | 165 | 1 | 2 | 3 | 3 |
| European Standard | GERMANY | UNS | WERKSTOFF NR. |
| B57S | Al-Mg-1 | A95005 | – |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Aluminium 5005 bars and rods find extensive use in architectural, structural, and decorative projects thanks to their remarkable corrosion resistance and smooth surface finish. In the construction industry, they are perfect for curtain walls, roofing sheets, and facades. Additionally, they are popular in signage, display panels, and appliance trim due to their superior anodizing capabilities. In marine and transportation applications, 5005 is often selected for non-load-bearing components that are exposed to moisture.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
