Dubai, UAE-based Kanish Metals is a well-known manufacturer and supplier of premium metal products catering to various industries with precision-engineered solutions. One of its specialized products includes Aluminium 2024 T3511 bars and rods, which have superior strength, fatigue life, and machinability. These materials find extensive applications across the aerospace, automotive, and other high-performance industries where high performance and durability are critical. The T3511 temper provides additional strength, greater resistance to stress, and long-term dependability. At Kanish Metals, we bridge the gap between cutting-edge production techniques and world-class customer service, providing custom-designed aluminium products that are compliant with the highest international standards.
Kanish Metals’ aluminium 2024 T3511 bars and rods consist of 90–94% aluminum, with 3.8–4.9% copper, 1.2–1.8% magnesium, and 0.3–0.9% manganese, as well as trace elements for improved performance. This alloy offers an excellent balance between strength and machinability and is therefore well-fitting for demanding engineering applications. The mechanical properties are tensile strength of 470–520 MPa, yield strength of approximately 325 MPa, and elongation of 10–15%. The T3511 temper contributes the benefit of being solution heat-treated and stress-relieved and presents improved crack resistance, fatigue strength, and stability of dimensions under heavy loads.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2024 T3511 | A92024 | 3.1355 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Aluminium 2024 T3511 is generally not recommended for welding due to its susceptibility to cracking and reduced strength after welding. However, specialized techniques like TIG welding and using filler materials can be employed with caution.
Yes, Aluminium 2024 T3511 bars are recyclable. Aluminium is highly recyclable without losing quality, making it an eco-friendly material for sustainable manufacturing and reducing environmental impact.
Aluminium 2024 T3511 is prone to corrosion, particularly in harsh environments with high humidity or exposure to saltwater. It is highly susceptible to pitting and stress corrosion cracking, though protective coatings can help mitigate this.
Aluminium 2024 T3511 rods and bars find widespread application in industries that need strong, light, and hard-wearing materials. Aerospace uses them in fuselage frames, wing spars, landing gear, and other high-stress structural parts. Automotive and defense industries use them in the production of vehicle frames, engine components, and precision structural parts where resistance to fatigue is essential. Their excellent machinability renders them suitable for intricate engineered components and precision fittings. Furthermore, the toughness of the alloy’s resistance to corrosive environments and cracking under stress provides confidence in critical applications requiring strength and durability over extended periods.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
