Kanish Metals stands out as a top manufacturer and supplier in Dubai, UAE, focusing on providing high-quality Titanium Grade 11 Forgings for essential industrial uses. Renowned for their remarkable corrosion resistance, lightweight strength, and excellent weldability, our Titanium Gr 11 products are crafted to comply with strict international standards, including ASTM and ASME specifications. These forgings are meticulously produced using cutting-edge technology and precision engineering, ensuring they perform reliably even in tough operating conditions. Trusted by industries like aerospace, marine, chemical, and medical, Kanish Metals offers a diverse range of customized Titanium Gr 11 Forgings aimed at enhancing performance, durability, and cost-effectiveness for clients worldwide.
Titanium Grade 11 Forgings are a corrosion-resistant alloy made up of titanium (≥99.5%), with a touch of palladium (0.12–0.25%) added for improved corrosion resistance in both reducing and oxidizing environments. They boast excellent ductility, toughness, and impact strength, even at cryogenic temperatures. Weighing in at about 4.5 g/cm³, they are both lightweight and strong, providing a fantastic strength-to-weight ratio. Titanium Gr 11 shows outstanding resistance to seawater, chlorides, and acidic conditions, making it perfect for harsh environments. These forgings are easy to weld, form, and machine, ensuring they deliver long-lasting performance and durability in demanding fields like chemical processing and marine engineering.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Titanium Gr 11 Forgings find their place in various industries that demand exceptional corrosion resistance and reliability in extreme conditions. They are perfect for chemical processing plants, heat exchangers, condensers, and reaction vessels, where safeguarding against chlorides and acidic environments is vital. In the marine industry, they are utilized for seawater piping systems, offshore platforms, and desalination plants, ensuring durability and performance in challenging settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
