Kanish Metals, a reputable manufacturer and supplier located in Dubai, UAE, proudly offers top-notch Hastelloy C276 Forgings designed to meet the rigorous demands of various industries. Renowned for its remarkable resistance to strong oxidizers and harsh corrosive environments, Hastelloy C276 is a go-to choice in chemical processing and marine applications. At Kanish Metals, we combine precision engineering with cutting-edge technology to produce forgings that promise durability, high performance, and reliability. With a robust supply network and a steadfast commitment to excellence, we serve clients both in the UAE and around the globe, ensuring timely delivery and superior product quality.
Hastelloy C276 Forgings are primarily made up of nickel, molybdenum, and chromium, with added iron, tungsten, and cobalt to boost strength and corrosion resistance. This unique blend offers exceptional protection against pitting, crevice corrosion, and stress corrosion cracking. On the mechanical side, Hastelloy C276 boasts a tensile strength of about 690 MPa, a yield strength of roughly 283 MPa, and impressive elongation, making it both tough and durable. It remains stable even at high temperatures and provides excellent formability and weldability for a variety of engineering applications.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Post-forging operations for Hastelloy C276 include heat treatment (such as annealing) to relieve stresses and improve mechanical properties, followed by surface finishing (like pickling or grinding) to remove oxides and enhance corrosion resistance.
To determine if Hastelloy C276 forgings meet your needs, assess their chemical composition, mechanical properties, and resistance to corrosion under the specific conditions of your application. Conduct testing such as tensile, impact, and corrosion tests for confirmation.
The ideal temperature range for forging Hastelloy C276 is between 1,900°F and 2,200°F (1,038°C to 1,204°C). This ensures proper deformation without compromising material properties.
These Hastelloy C276 Forgings are widely utilized in chemical processing plants for managing acidic and highly corrosive substances. Their outstanding resistance to seawater and marine conditions makes them perfect for offshore applications, desalination equipment, and shipbuilding. In pollution control, they find use in flue gas scrubbers, ducts, and absorbers. Industries such as power generation, pharmaceuticals, and pulp and paper also depend on these forgings for reliable performance in challenging environments. Thanks to their exceptional durability and corrosion resistance, Hastelloy C276 Forgings guarantee a long service life in critical and demanding industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
