Kanish Metals stands out as a reliable manufacturer and supplier of Hastelloy C22 Forgings in Dubai, UAE, meeting a wide range of industrial needs with top-notch products. Known for its exceptional resistance to both oxidizing and reducing agents, Hastelloy C22 is a nickel-chromium-molybdenum alloy that guarantees outstanding performance even in the toughest environments. Kanish Metals provides precision-engineered forgings that adhere to global quality standards, ensuring durability, strength, and resistance to corrosion. With a strong focus on customer satisfaction, the company caters to sectors like chemical processing, petrochemicals, and marine applications, delivering reliability and efficiency in demanding operational settings.
Hastelloy C22 Forgings are primarily made of nickel, along with notable amounts of chromium, molybdenum, and tungsten, which enhance their resistance to corrosion, pitting, and crevice attack. This alloy boasts impressive mechanical strength, with a tensile strength of around 690 MPa and a yield strength of about 310 MPa. It retains good ductility and toughness even at high temperatures, ensuring stability in aggressive environments. The blend of high mechanical properties and robust corrosion resistance makes Hastelloy C22 perfect for critical applications that require durability and reliability under challenging conditions.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C22 Forging UNS (N06022), DIN (2.4602)
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C22 | Balance | 0.010 max | 12.5-14.5 | 0.50 max | 0.08 max | 2-6 | 0.02 max | 0.02 max | 2.5 max | 20-22.5 | 2.5-3.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa – 690 | Psi – 45000, MPa – 310 | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 |
Yes, Hastelloy C22 can be forged into custom shapes, as it has good formability and strength at elevated temperatures. However, it requires precise control during the forging process to maintain its properties.
The ideal temperature range for forging Hastelloy C22 is between 2,100°F (1,150°C) and 2,300°F (1,260°C). This ensures optimal formability and minimizes the risk of damaging the material's properties.
The forging process for Hastelloy C22 typically takes several minutes to hours, depending on the complexity and size of the part. The heating and cooling cycles also influence the total time required for forging.
Hastelloy C22 Forgings find extensive use in industries where resistance to highly corrosive chemicals is crucial. They are commonly utilized in chemical processing plants for reactors, heat exchangers, and scrubbers, thanks to their resistance to oxidizers and reducing agents. In marine applications, these forgings provide durability against seawater corrosion, while in the pharmaceutical and food processing industries, they ensure hygienic and long-lasting performance. Furthermore, Hastelloy C22 is also used in pollution control, pulp and paper, and waste treatment sectors, where exposure to aggressive fluids and harsh environments demands materials that guarantee a long service life and dependable performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
