Kanish Metals stands out as a leading manufacturer and supplier of stainless steel products in Dubai, UAE, with a particular focus on stainless steel 904L hex bars. Renowned for their commitment to quality and precision, Kanish Metals provides 904L hex bars that excel in environments where high corrosion resistance is a must, especially in harsh conditions. These hex bars are sourced from reputable manufacturers and find applications in a variety of industries, including chemical processing, marine, and petrochemical sectors. With a strong emphasis on consistent product quality, timely deliveries, and a customer-centric approach, Kanish Metals has established itself as a trustworthy partner for stainless steel solutions in the UAE and beyond.
Stainless Steel 904L hex bars are made up of iron, chromium (19-23%), nickel (24-26%), and molybdenum (4-5%), along with trace amounts of copper and other elements. This alloy is engineered for outstanding resistance to corrosion, particularly against sulfuric acid, chlorides, and other aggressive chemicals. Its mechanical properties boast high tensile strength (up to 1000 MPa), excellent resistance to pitting and crevice corrosion, and commendable ductility. The material strikes a perfect balance between strength, flexibility, and resistance to oxidation and corrosion, even in acidic settings, making it a top choice for demanding applications.
| Specifications | ASTM B649 / ASME SB 649 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Stainless Steel Round Bar | Outside Diameter in the range of 4mm to 500mm |
| Stainless Steel Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Stainless Steel Hex Bar | 18mm – 57mm (11/16″ to 2-3/4″) |
| Stainless Steel Square Bar | 18mm – 47mm (11/16″ to 1-3/4″) |
| Stainless Steel Flat Bar | 1/2″ to 10″ in thickness range of 2 mm to 150mm, Custom Size Stainless Steel Flats available |
| Range | 3.17 MM TO 350 MM DIA |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Finishing | Bright, Polish & Black |
| Form of | Hex, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Other Services | Machining (CNC), Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polish, Rolling, Forging, Cutting, Bending, Minor Fabrication, |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 904L Hex Bar offers excellent corrosion resistance, especially against pitting, crevice, and stress corrosion cracking. Its high nickel and chromium content make it ideal for harsh environments like chemical processing, marine, and power plants. The hexagonal shape provides enhanced strength and machinability, ensuring durability and reliability in industrial applications.
SS 904L outperforms many stainless steels, such as 304 and 316, in corrosion resistance due to its higher nickel and molybdenum content. This composition enhances resistance to chloride-induced pitting and crevice corrosion, making it ideal for environments with high chloride concentrations or acidic exposure, such as chemical and marine applications.
SS 904L Hex Bar is commonly used in the chemical, petrochemical, marine, and pharmaceutical industries. It is ideal for applications such as heat exchangers, reactor vessels, pressure vessels, and piping systems, where resistance to corrosion, especially in acidic and chloride-rich environments, is critical for long-term durability and performance.
Stainless Steel 904L hex bars are essential in industries that demand high corrosion resistance and can withstand extreme conditions. In chemical processing facilities, they are crucial for manufacturing components like heat exchangers, reactors, and piping systems, where corrosion resistance is vital. In marine settings, 904L hex bars are employed for parts that face saltwater and corrosive environments, such as offshore platforms and marine equipment. They also play a significant role in the pharmaceutical, food processing, and petrochemical industries, where maintaining integrity in harsh operating conditions is paramount.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
