Kanish Metals stands out as a reliable manufacturer and supplier of Nimonic 263 Bars and Rods in Dubai, UAE. They offer top-notch products designed for exceptional strength, corrosion resistance, and durability, even in the harshest environments. Nimonic 263 (UNS N07263) is a unique nickel-cobalt-chromium alloy, enhanced with molybdenum, titanium, and aluminum, which gives it remarkable mechanical properties at high temperatures, reaching up to 900°C. This alloy boasts impressive creep resistance, excellent weldability, and solid oxidation resistance, making it a go-to choice for critical engineering applications. Crafted with precision and adhering to strict quality standards, Kanish Metals’ Nimonic 263 Bars and Rods guarantee dimensional accuracy, toughness, and a long service life in demanding industries.
These Bars and Rods consist of 49–51% nickel, 19–21% chromium, 19–21% cobalt, 5.6–6.1% molybdenum, 1.9–2.4% titanium, and 0.3–0.6% aluminum, along with carefully controlled amounts of manganese, iron, and silicon. They deliver a tensile strength of around 1000 MPa, a yield strength of 760 MPa, and an elongation of 20–25%. The alloy ensures excellent creep rupture strength, thermal stability, and oxidation resistance while remaining easy to weld and fabricate.
Dimension : EN, DIN, JIS, ASTM, BS, ASME, AISI
Grade : Nimonic 263 (UNS No. N07263) Round Bars 2.4650
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
Application : Chemical process, Food processing, Petrochemical, Pollution control, Pulp and Paper, Refining
Condition : Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished.
Our Nimonic Alloy 263 Round Bars conforms to NACE MR0175/ISO 15156
| Grade | C | Cr | Co | Ti | Al | Si | Cu | Mn |
|---|---|---|---|---|---|---|---|---|
| Nimonic Alloy 263 | 0.04-0.08 | 19 – 21 | 19 – 21 | 1.90 – 2.40 | 0.60 max | 0.40 max | 0.20 max | 0.60 max |
| Density | Melting Point | Coefficient of Expansion | Modulus of Rigidity | Modulus of Elasticity (Annealed + Aged) (Spring Temper + Aged) |
|---|---|---|---|---|
| 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Nimonic Alloy 263 | 2.4650 | N07263 |
Nimonic 263 rods typically come in standard sizes ranging from 1/4 inch to 12 inches in diameter, with lengths varying from 3 feet to 12 feet, depending on the supplier.
Yes, Nimonic 263 rods can be supplied in both polished and matte finishes, depending on the supplier's capabilities and the specific requirements of the application.
Nimonic 263 rods are available in various diameters, typically ranging from 1/8" to 12" or more. Common finishes include bright, cold drawn, and hot rolled, depending on specific requirements.
Nimonic 263 Bars and Rods find their place in industries that require outstanding strength, corrosion resistance, and high-temperature performance. They’re perfect for aerospace applications, including turbine engines, rings, and casings, as well as for gas turbines in power generation plants. Their remarkable creep and fatigue resistance make them ideal for petrochemical processing, nuclear reactors, and heat treatment equipment. Additionally, they are used in automotive racing engines, furnace components, and marine environments that demand long-lasting durability under tough conditions. With a perfect blend of mechanical strength, oxidation resistance, and weldability, Nimonic 263 Bars and Rods are a trusted choice for high-performance applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
