Kanish Metals stands out as a leading manufacturer and supplier of high-performance Monel K500 Forgings in Dubai, UAE. We take pride in providing precision-engineered forged components crafted from Monel K500, a nickel-copper alloy celebrated for its remarkable strength, corrosion resistance, and durability. Our forgings are tailored to meet the rigorous demands of industries such as marine, chemical, oil & gas, and aerospace. With cutting-edge manufacturing facilities and stringent quality control measures, Kanish Metals guarantees exceptional product reliability, timely delivery, and complete customer satisfaction. Count on us as your trusted partner for top-notch Monel K500 forgings throughout the UAE and beyond.
Monel K500 Forgings are primarily made up of nickel (about 63%) and copper (27–33%), with minor additions of aluminum (2.3–3.15%) and titanium (0.35–0.85%). These elements boost the alloy’s strength through a process called age hardening. Monel K500 showcases a tensile strength of roughly 960 MPa and a yield strength of around 690 MPa, along with impressive toughness across a broad temperature spectrum. It offers outstanding corrosion resistance, particularly in marine and chemical settings, and remains non-magnetic at room temperature. This unique blend of high strength, hardness, and corrosion resistance makes it perfect for demanding service conditions.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel K500 Forging UNS (N05500), DIN (2.4375)
BS3072 NA18, QQ-N-286, DIN 17750, ISO 6208
AMS 4676, BS3076 NA18, ASTM B 865, DIN 17752, QQ-N-286, ISO 9723
AMS 4676, ISO 6208, ASTM B 865, DIN 17752, QQ-N-286
BS3076, NA18, DIN 17753, QQ-N-286, ISO 9724
DIN 17754, QQ-N-286, ISO 9725
UNS N05500, BS6076 NA13, Werkstoff Nr. 2.4375, MIL-N-24549, NACE MR-01-75
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Monel K500 Forgings find extensive use in applications that demand high strength and exceptional corrosion resistance, particularly in challenging marine and chemical environments. They are commonly utilized in pump and valve components, marine propeller shafts, oil well tools, fasteners, and springs. This alloy is particularly suited for sour gas (H₂S) environments and is frequently employed in offshore platforms, chemical processing facilities, and heat exchangers. Its non-magnetic characteristics also make it ideal for electronic components and instrumentation. Monel K500 forgings are a trusted choice for those seeking reliability and performance in tough conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
