Kanish Metals stands out as a reliable manufacturer and supplier of Monel 400 Forgings in Dubai, UAE. They pride themselves on delivering top-notch products that are designed for exceptional corrosion resistance, strength, and durability. Monel 400 (UNS N04400) is a nickel-copper alloy celebrated for its remarkable ability to resist seawater, hydrofluoric acid, and alkalis, making it perfect for environments that are tough on materials. Each Monel 400 Forging is produced under rigorous quality control standards, ensuring they boast dimensional accuracy, toughness, and long-lasting performance, which is crucial for applications in chemical processing, marine, aerospace, and power generation sectors.
These forgings are primarily made up of 63% nickel and 28–34% copper, with minor amounts of iron, manganese, carbon, and silicon. They deliver impressive tensile strength ranging from about 550 to 690 MPa, yield strength between 240 and 450 MPa, and elongation rates of 30 to 50%, depending on the specific grade. The alloy is known for its outstanding corrosion resistance in seawater, acids, and alkalis, along with excellent mechanical stability and toughness, even in high-temperature and harsh chemical environments. Plus, they maintain good weldability and formability, making them adaptable for a variety of industrial uses.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel 400 Forging UNS (N04400), DIN (2.4360)
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
| Density | Melting Range | Curie Temperature | Electricity Resistivity | |||
| g/cm3 | lb/in3 | °F | °C | °F | °C | µΩ·m |
| 8.8 | 0.318 | 2370-2460 | 1300-1350 | 70-120 | 21-49 | 547 |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Temperature control is crucial in forging Monel 400, ensuring optimal mechanical properties, preventing defects, and maintaining its corrosion resistance and strength. Proper control minimizes cracking and enhances overall quality.
Assess Monel 400's forging strength for aerospace by evaluating its tensile strength, yield strength, and fatigue resistance under simulated operating conditions. Conduct tests for thermal stability and corrosion resistance to ensure suitability.
Evaluate Monel 400 forgings by checking their mechanical properties, corrosion resistance, and compatibility with your operating environment. Review certifications, standards, and conduct application-specific testing for assurance.
Monel 400 Forgings are extensively utilized in industries that demand high-performance materials capable of enduring extreme conditions. They are perfect for chemical processing equipment, marine shafts, pump and valve components, heat exchangers, and aerospace applications. Their exceptional resistance to pitting, stress corrosion cracking, and oxidation makes them ideal for offshore oil and gas facilities, nuclear reactors, desalination plants, and the petrochemical industry. Additionally, they find their place in high-performance automotive and industrial machinery where long-term durability, corrosion resistance, and structural integrity are essential. Monel 400 Forgings offer a dependable mix of mechanical strength, corrosion resistance, and toughness, making them a top choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
