Kanish Metals is a leading manufacturer and supplier of Alloy Steel Rectangular Bars in Dubai, UAE, manufactured to deliver exceptional strength, durability, and resistance to wear for numerous demanding applications. The bars are manufactured from high-quality alloy steels to deliver optimal performance in automotive, aerospace, construction, and manufacturing industries. The rectangular bars are offered in different sizes and grades to meet specific design specifications. Kanish Metals provides products following global standards, ensuring reliability and performance in high and low-temperature uses.
Alloy Steel Rectangular Bars consist of a combination of carbon, manganese, chromium, and molybdenum. Vanadium or nickel can be present, depending on the grade. The bars provide high tensile strength (600–1100 MPa), yield strength (350–850 MPa), and hardness up to 55 HRC. Excellent wear resistance, corrosion resistance, and resistance to high-temperature exposure characterize these bars. The alloy makes them weldable and machinable, suitable for numerous fabrication processes.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Range | 5mm to 500mm Dia in 100mm to 6000mm Length |
| Diameter | 10 mm To 200 mm |
| Thickenss | 0.5mm to 500mm Diameter |
| High Speed Steel (HSS), HCHCR & OHNS in Grade | M2, M3, M35, M42, T-1, T-4, T-15, T-42, D2, D3, H11, H13, OHNS-01 & EN52 |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 1000 mm Long To 6000 mm Long |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | C | Cr | Mn | Mo | P | S | Si | Ni |
| F5 | 0.15 Max | 4.0-6.0 | 0.30-0.60 | 0.44-0.65 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F1 | 0.15 Max | 3.0-5.0 | 0.30-0.60 | 0.40-0.50 | 0.035 Max | 0.030 Max | 0.50 Max | 0.50 Max |
| F22 | 0.05-0.15 | 2.00-2.50 | 0.30-0.60 | 0.90-1.10 | 0.035 Max | 0.040 Max | 0.50 Max | – |
| F91 | 0.08-0.12 | 8.0-9.5 | 0.30-0.60 | 0.85-1.05 | 0.020 Max | 0.010 Max | 0.20-0.50 | 0.40 Max |
| F9 | 0.15 Max | 8.0-10.0 | 0.30-0.60 | 0.90- 1.10 | 0.030 Max | 0.030 Max | 0.50- 1.00 | – |
| F11 | 0.10-0.20 | 1.00-1.50 | 0.40-0.65 | 0.44-0.65 | 0.025 Max | 0.040 Max | 0.50-0.80 | – |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min |
| F9 | 415 | 30 | 205 |
| F5 | 275 | 485 | 20 |
Alloy steel rectangular bars are not inherently environmentally friendly due to energy-intensive production processes and mining of raw materials. However, they can be recycled, reducing their environmental impact.
Yes, alloy steel rectangular bars are customizable in terms of dimensions, alloy composition, and surface finish. They can be tailored to specific applications, including strength, corrosion resistance, and shape requirements.
Alloy Steel Rectangular Bars find application in those industries that need high-strength materials for machinery and structural components. They are typically seen in bridge, building, and industrial plant construction. In the automobile industry, they are utilized to manufacture parts such as chassis components, brackets, and gears. Alloy Steel Rectangular Bars also find applications in the production of heavy machinery, oil and gas pipeline systems, and pressure vessels, where they need to be resistant to heat, corrosion, and fatigue. They are also employed in instances where there is high wear resistance, such as earth-moving machinery and mining equipment.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
