Kanish Metals is a trusted producer and supplier of ST 52.3 Round Bars based in Dubai, UAE, serving diversified industrial sectors with superior carbon steel solutions. ST 52.3 is a low alloy steel used in construction that exhibits superior strength, weldability, and toughness. Kanish Metals offers accurately produced round bars according to international standards that are acceptable for heavy engineering and construction needs. With quality focus, timely supply, and customer-specific needs, Kanish Metals has gained a reputable name in supplying ST 52.3 round bars to various UAE industries and international markets.
ST 52.3 is a low alloy structural steel with high strength and material composition generally consisting of carbon (0.22% max), manganese (1.6% max), trace amounts of silicon, phosphorus, and sulfur. It provides a tensile strength of 490–630 MPa, a yield strength of about 355 MPa, and elongation of about 21%. ST 52.3 steel possesses good impact resistance at low temperatures and is very weldable without preheating. ST 52.3 is therefore ideal for static as well as dynamic loading situations in the structural and mechanical fields.
Alloy 20 Round Bar Specification : ASTM B473 , ASME SB473
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.
| Carbon Steel | C | Si | Mn | P | S | Cu | N |
| ST 52 | 0,22 | 0,55 | 1,60 | 0,030 | 0,030 | 0,55 | 0,012 |
| The final delivery condition | Cold drawn(Mandatory) BK1） | Cold drawn(Soft) BKW1） | Cold Drawn and Stress Release (BKS) | Anneal (GBK)1） | Normalizing (NBK)1） | |||||||||
| Kinds of Steel | Tensile | Elongation | Tensile | Elongation | Tensile | Yield point | Elongation | Tensile | Elongation | Tensile | Yield point | Elongation | ||
| Steel grade | Material number | No less than | ||||||||||||
| Rm | A5 | Rm | A5 | Rm | ReH | A5 | Rm | A5 | Rm | ReH2) | A5 | |||
| N/mm2 | % | N/mm2 | % | N/mm2 | N/mm2 | % | N/mm2 | % | N/mm2 | N/mm2 | % | |||
| St52 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 420 | 10 | 490 | 22 | 490~630 | 355 | 22 | |
|
DIN |
EN |
JIS |
ISO |
ASTM |
GB |
|
|
ST52-3 |
S355JR |
SM490A |
FE510B |
E36-2 |
A572Gr.50 |
Q345B |
Considerations for selecting ST 52.3 Round Bar include its mechanical properties, tensile strength, corrosion resistance, application requirements, and cost-effectiveness.
ST 52.3 Round Bar generally does not require corrosion protection coatings for indoor applications but may need coatings for outdoor or harsh environments to enhance its durability.
ST 52.3 Round Bar can be used for underground applications, but it may require additional corrosion protection to ensure longevity in moist or aggressive environments.
ST 52.3 Round Bars find extensive application in construction, automobile, machinery, and heavy engineering sectors. Typical uses involve structural supports, frames, shafts, axles, parts of cranes, and mechanical parts that are subjected to heavy loads and stress. Because of its high strength and favorable machinability, it is also applied in the production of hydraulic systems, bridges, and pressure vessels. Its weldability and toughness make it suitable for fabrication and assembly work in industrial projects. ST 52.3 round bars are particularly prized in situations where cost savings, resistance to fatigue, and toughness are paramount.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
