Kanish Metals stands out as a reliable manufacturer and supplier of Copper C10200 Bars and Rods right here in Dubai, UAE. We take pride in offering top-notch products that cater to the varied needs of industries around the globe. With its remarkable purity and outstanding conductivity, Copper C10200 is a go-to choice for demanding electrical and thermal applications. At Kanish Metals, we focus on precision engineering, durability, and adhering to international quality standards in every item we produce. Our Copper C10200 Bars and Rods come in a range of dimensions and finishes, making them perfect for sectors like power generation, electrical systems, automotive, and general engineering.
These Copper C10200 Bars and Rods are crafted from high-purity copper, boasting a minimum of 99.95% copper content and minimal oxygen levels, which significantly boosts conductivity and corrosion resistance. They also showcase impressive mechanical properties, such as excellent ductility, formability, and superior thermal conductivity. With tensile strength between 210 and 370 MPa and remarkable elongation, they strike a perfect balance between strength and workability. These mechanical traits make them ideal for high-performance applications where reliability, electrical efficiency, and resistance to wear are essential.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Copper Grades | C10200 |
| Melting Point – Solidus ⁰F | 1981 |
| Melting Point – Liquidus ⁰F | 1981 |
| Density lb/cu in. at 68⁰F | 0.323 |
| Electrical Conductivity % IACS at 68⁰F | 101 |
| Specific Gravity | 8.94 |
| Specific Heat Capacity Btu/lb/⁰F @ 68 ⁰F | 0.092 |
| Thermal Conductivity Btu/sq ft/ft hr/ ⁰F at 68⁰F | 226 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-392 ⁰F) | 9.6 |
| Modulus of Rigidity ksi | 6400 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-212 ⁰F) | 9.4 |
| Modulus of Elasticity in Tension ksi | 17000 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-572 ⁰F) | 9.8 |
| Standards | Country | Value |
|---|---|---|
| EN | Europe | Cu-OF |
| DIN CEN/TS 13388 | Germany | CW008A |
| UNS | – | C10200 |
| JIS | Japan | C1020 |
| GB | China | TU1 |
| BS | England | C102 |
| Thermal Properties | Metric | English |
|---|---|---|
| Annealing Point | >= 371 °C | >= 700 °F |
| CTE, linear | 17.0 µm/m-°C @Temperature 20.0 – 100 °C | 9.44 µin/in-°F @Temperature 68.0 – 212 °F |
| 17.7 µm/m-°C @Temperature 20.0 – 300 °C | 9.83 µin/in-°F @Temperature 68.0 – 572 °F | |
| 17.3 µm/m-°C @Temperature 20.0 – 200 °C | 9.61 µin/in-°F @Temperature 68.0 – 392 °F | |
| Thermal Conductivity | 391 W/m-K @Temperature 20.0 °C | 2710 BTU-in/hr-ft²-°F @Temperature 68.0 °F |
| Melting Point | 1083 °C | 1981 °F |
| Specific Heat Capacity | 0.385 J/g-°C @Temperature 20.0 °C | 0.0920 BTU/lb-°F @Temperature 68.0 °F |
| Property/unit | Condition | Min | Max |
|---|---|---|---|
| Tensile Strength (N/mm2) | 1/2H | 290 | |
| Elongation in 5.65 Cross sectional area | O | 32 | |
| Tensile Strength (N/mm2) | H | 350 | |
| Tensile Strength (N/mm2) | O | 260 | |
| Elongation in 5.65Cross sectional area | 1/2H | 4 |
Yes, Copper C10200 Bars and Rods are fully recyclable. Copper retains its properties after recycling, making it an environmentally friendly and sustainable material for repeated use in various industries.
Copper C10200 Bars and Rods generally do not require corrosion protection coatings as copper naturally resists corrosion. However, in certain aggressive environments, protective coatings may be used to enhance durability.
Yes, Copper C10200 Bars and Rods can be welded using techniques like TIG and MIG welding. Their high conductivity and low oxygen content ensure strong and reliable welds for various applications.
Across various industries, Copper C10200 Bars and Rods are highly sought after for their exceptional electrical and thermal conductivity. They’re crucial in the production of electrical conductors, bus bars, transformers, and switchgear components. Their corrosion resistance and ductility also make them a great fit for plumbing, heat exchangers, and industrial machinery. In the automotive and aerospace fields, you’ll find them in wiring systems, connectors, and precision components. Plus, they play a vital role in construction, telecommunication equipment, and renewable energy systems, showcasing their versatility and dependability in critical, high-performance applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
