Kanish Metals is a reliable manufacturer and exporter of Super Duplex Steel Ferralium 255 Rods and Bars in Dubai, UAE. With their superior mechanical properties and high corrosion resistance, Ferralium 255 products are engineered to withstand rough conditions. We export these rods and bars in multiple sizes and grades so that our customers can avail of products that match their needs. Optimal for oil and gas, chemical, and marine industries, Ferralium 255 Bars and Rods ensure enduring reliability in severely corrosive conditions.
Super Duplex Steel Ferralium 255 is an alloy consisting mainly of 25% chromium, 7% nickel, and 3.5% molybdenum, with trace amounts of copper and nitrogen. The remarkable combination yields extraordinary resistance against pitting, crevice corrosion, and stress corrosion cracking. Ferralium 255 possesses high tensile strength, usually ranging from 85-95 ksi, and excellent fatigue and impact resistance, which makes it perfect for use in high-pressure and severe-temperature applications. With a hardness rating of about 290-330 HB, Ferralium 255 also has good weldability, enabling it to be used extensively in mission-critical applications.
| Grade | Ferralium 255 |
|---|---|
| Specification | Super Duplex Steel Ferralium 255 Round Bar |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Section | 3.0 to 12.0mm thickness |
| Round bar size | Diameter: 3-~800mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter | Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Technique | Ferralium 255 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Ferralium 2507 Round Bar, Rod, T-Bar, Super Duplex Steel Channel Bar, Precision Ground Bar, Super Duplex Steel Flat Bar, Super Duplex Steel Square Bar, Super Duplex Steel Blocks, Super Duplex Steel Round Rod, Super Duplex Steel Rings, Super Duplex Steel Hollow, Super Duplex Steel Triangle, Rectangle, Hex (A/F), Super Duplex Steel Threaded, Ferralium 2507 Half Round Bar, Profiles, Super Duplex Steel Billet, Super Duplex Steel Ingot, I/H Bar, Forging etc. |
| Mo | Cu | Cr | Ni | N | Si | Mn | W | P | S | C | Fe |
| 3.5 | 1.75 | 26 | 6.3 | 0.23 | 0.15 | 0.5 | 1 max | 0.025 max | 0.025 max | Balance | 0.005 max |
| Yield Strength (0.2%Offset) | MPa – 570-600 |
| Tensile Strength | MPa – 790 |
| Elongation | 25 % |
| STANDARD | UNS | DIN |
|---|---|---|
| Ferralium 2507 round bar | S32550 | 1.4507 |
Yes, Super Duplex Steel Ferralium 255 Bars can be welded using suitable techniques like TIG, MIG, or SMAW, ensuring precise heat input control to prevent phase imbalance. Pre-heating and post-weld heat treatments may be required for optimal weld integrity.
Super Duplex Steel Ferralium 255 Rods are highly resistant to galvanic corrosion due to their excellent corrosion resistance properties. However, they may still experience some susceptibility in highly corrosive environments when coupled with more anodic materials.
Super Duplex Steel Ferralium 255 rods are available in a wide range of sizes, typically from 3mm to 500mm in diameter. They are offered in finishes such as hot-rolled, cold-drawn, and polished for various applications.
Super Duplex Steel Ferralium 255 Bars and Rods find extensive application in those industries that require both high strength and corrosion resistance. These rods and bars are superior in extreme conditions, such as offshore oil and gas development, marine use, and chemical processing. Ferralium 255 finds excellent application in subsea equipment, pipelines, pressure vessels, and heat exchangers. Ferralium 255 is also utilized in desalination plants and power stations, where it can resist corrosive seawater and acidic/alkaline conditions to ensure long-lasting durability and superior performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
