Kanish Metals stands out as a leading manufacturer and supplier of high-performance Inconel 617 Bars and Rods in Dubai, UAE, providing innovative material solutions designed for extreme conditions. These Inconel 617 products are celebrated for their remarkable high-temperature strength, resistance to oxidation, and metallurgical stability, making them perfect for the toughest industrial applications. At Kanish Metals, we take pride in ensuring that every bar and rod adheres to strict international standards through meticulous manufacturing and thorough quality checks. With a robust supply chain and a dedication to excellence, we cater to the aerospace, power generation, petrochemical, and industrial sectors both in the UAE and globally, offering both standard and custom-sized Inconel 617 products.
Inconel 617 Bars and Rods are primarily made up of Nickel (Ni ~44.5–60%), with notable amounts of Chromium (~20–24%), Cobalt (~10–15%), and Molybdenum (~8–10%), along with small quantities of Aluminum, Carbon, and Iron. This nickel-chromium-cobalt alloy showcases outstanding high-temperature strength, oxidation resistance, and metallurgical stability. Its mechanical properties include a tensile strength exceeding 760 MPa, yield strength around 350 MPa, and impressive ductility even at high temperatures. The alloy retains its structural integrity up to 1100°C and is resistant to carburization and corrosion, making it an excellent choice for harsh thermal and chemical environments.
| Standards | ASTM B166, ASME SB 166, AMS 5887 |
|---|---|
| Specifications | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 617 Inconel Round Bars size | Diameter: 3-~800mm |
| Inconel 617 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Inconel 617 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Inconel 617 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 617 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Inconel 617 Billet Size | 1/2 to 495mm Diameter |
| Inconel 617 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Inconel 617 Hex Bar size | 2-100mm A/F |
| Inconel 617 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 617 | 2.4663 | N06617 |
| Grade | Ni | Cr | Fe | C | Mn | S | Mo | Si | Co |
| Inconel 617 | 48.85 – 62 | 20 – 24.0 | Balance | ≤ 0.15 | ≤ 1 | – | 8 – 10 | ≤ 1 | 10-15 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.3g/cm³ | 1363°C | ≥ 485 MPa | ≥ 275 MPa | 25 % |
Inconel 617 Bars and Rods find extensive use in high-temperature and high-stress applications across various industries, including aerospace, power generation, and petrochemical processing. They are particularly well-suited for creating gas turbine components, heat exchangers, combustion chambers, and ducting systems, where resistance to oxidation and thermal fatigue is essential. In the energy sector, these rods are utilized in coal gasification plants and components for nuclear reactors, showcasing their versatility and reliability in demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
