Kanish Metals is a reliable supplier and manufacturer of Hastelloy Rectangular Bars, situated in Dubai, UAE, offering corrosion-resistant alloy solutions for extremely demanding industrial conditions. Hastelloy rectangular bars are renowned for their superior resistance against various aggressive chemicals, such as highly corrosive acids and oxidizing agents. Kanish Metals provides these bars in different grades of Hastelloy C22, C276, B2, etc., as per international standards and customer requirements. With intense focus on quality, accuracy, and timely delivery, Kanish Metals caters to the chemical, marine, aviation, and power generation sectors in the UAE and worldwide.
Hastelloy Rectangular Bars contain nickel as a major component, with substantial amounts of molybdenum, chromium, iron, and cobalt, depending on the type. The elements provide the metal excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. The usual mechanical properties are tensile strength of 690–850 MPa and good ductility and formability. The bars preserve their structure in oxidizing and reducing conditions and are ideally suited for application under high-temperature and high-pressure conditions, providing enduring performance and dependability.
| Specification | ASTM B574 UNS N06022, ASTM B574 / ASME SB574 / AMS 5766 |
|---|---|
| Alloy C22 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Hastelloy C22 Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Hastelloy C22 Round, Welding Rod, T-Bar, Rod, Precision Ground Bar, Channel Bar, Square, Flat Bar, Blocks, Round Rod, Hollow, Rings, Rectangle, Hex (A/F), Triangle, Threaded, Profiles, Billet, Ingot, I/H Bar, Half Round Bar, Forging etc. |
| Material | Ni | C | Cr | Co | Fe | Mn | Mo | P | Si | S | W | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy | Bal | 0.010 max | 20 – 22.5 | 2.5 max | 2 – 6 | 0.50 max | 12.5 – 14.5 | 0.02 max | 0.08 max | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
Hastelloy Rectangular Bars are highly resistant to galvanic corrosion due to their corrosion-resistant alloy composition. However, in certain environments with dissimilar metals, they could be susceptible to this type of corrosion.
Yes, Hastelloy Rectangular Bars can be recycled. Their nickel-based composition allows for efficient recycling, making them a sustainable option when properly processed at recycling facilities.
Yes, Hastelloy Rectangular Bars are suitable for cryogenic applications due to their excellent toughness and resistance to brittle fracture at low temperatures, ensuring reliable performance in extreme cold environments.
Hastelloy Rectangular Bars are extensively applied in corrosion resistance, high-temperature, and mechanical stress-demanding applications. They are deployed in chemical processing facilities, heat exchangers, reactor vessels, scrubbers, marine equipment, and pollution control equipment. Their flat shape is most suitable for frames, brackets, structural supports, and precision machined parts. These bars are particularly effective in hydrochloric acid, sulfuric acid, and chlorine compounds environments. Because they are strong and tough, Hastelloy rectangular bars are the best option for critical parts used in industries that cannot afford to fail.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
