Dubai, UAE-based Kanish Metals is a reliable producer and supplier of premium-quality steel and alloy products to various industrial segments. Backed by deep focus on precision, ruggedness, and customer satisfaction, the company delivers world-class solutions in accordance with international standards. Among its range of specialized products is Copper-Nickel Bright Bars, which are highly acclaimed for their superior corrosion resistance, mechanical properties, and optimal performance in tough environments. These bars are commonly applied in marine, industrial, and power industries because of their strength and adaptability. With over decades of experience, Kanish Metals remains a leading provider of innovative metal solutions in the UAE.
Copper-Nickel Bright Bars consist mainly of 90% copper and 10% nickel with minor additions of manganese and iron that improve strength and corrosion resistance. They display tensile strength of 550–700 MPa, yield strength of 200–400 MPa, and elongation of 30–40%. The alloy gives a great blend of strength, ductility, and formability, making it suitable for diverse engineering applications. Its high resistance to seawater corrosion and severe chemical environments and good thermal conductivity make it suitable for demanding marine, industrial, and electrical applications.
Specification : EN, DIN, JIS, ASTM, BS, ASME, AISI
Standard Specification : ASTM B111 / ASME SB111
Size : 15NB to 150NB IN
Diameter : 3.17mm to 350mm diameter
Length : 100 mm to 3000 mm Long & Above
Tolerance : H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Hairline
Condition : Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000PSi |
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
| Bar Diameter (mm) | Weight (kg/m) |
|---|---|
| 6 | 0.22 |
| 8 | 0.39 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.58 |
| 20 | 2.47 |
| 25 | 3.85 |
| 32 | 6.31 |
| 40 | 9.86 |
| 45 | 12.5 |
| 50 | 15.4 |
| 60 | 22.2 |
| 65 | 26.0 |
| 75 | 34.7 |
| 90 | 49.9 |
| 100 | 61.6 |
Yes, Copper Nickel bright bars are highly customizable in terms of dimensions, lengths, and surface finishes to meet specific industry requirements, providing tailored solutions for various applications and projects.
Copper-Nickel Bright Bars find widespread application in processes needing long-term durability and corrosion resistance. In the marine industry, they are used in ship construction, offshore oil platforms, and desalination plants for the production of pumps, valves, condenser tubes, and seawater piping. Their biofouling and seawater corrosion resistance leads to surefooted performance in challenging marine environments. In industrial use, they are applied in chemical process plants, insulation systems, and power generation plants. Their superior electrical and thermal conductivity also makes them ideal for electrical components and connectors. Balancing strength with corrosion resistance, copper-nickel bright bars are still an ideal material for applications under extreme conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
