Headquartered in Dubai, UAE, Kanish Metals is a reliable manufacturer and supplier of high-quality steel and alloy products, with specialization in Copper-Nickel 90/10 Forgings. Renowned for precision, reliability, and customer-oriented solutions, the company caters to industries including marine, chemical, and power generation. Copper-Nickel 90/10 forgings made of 90% copper and 10% nickel are known for superior corrosion resistance, endurance, and mechanical stability. These characteristics render them best suited for aggressive industrial and marine applications, such as seawater systems. Backed by a promise of high quality, timely delivery, and unsurpassed performance, Kanish Metals guarantees that its forgings conform to international standards of quality.
Copper-Nickel 90/10 Forgings consist of 90% copper and about 10% nickel with trace levels of iron and manganese for increased strength and corrosion resistance. This alloy has excellent seawater durability along with superior weldability and heat conductivity. The mechanical properties are tensile strength of 310–480 MPa, yield strength of 160–280 MPa, and elongation of 30–50%. It also exhibits a Brinell hardness of 90–180. These qualities along with stress corrosion and biofouling resistance make Copper-Nickel 90/10 a perfect choice for challenging engineering and industrial applications.
| Standards | ASTM B151 / ASME SB151 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI all International Standards |
| Diameter | Outside Diameter in the range of 4mm to 500mm |
| Width | 1m to 48″ |
| Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm |
| Wire Length | Max 12000 mm |
| Wire Diameter | 5.5 – 400 mm |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Types | Round, Square, Hex (A/F), Flat, Square, Rectangle, Billet, Ingot, Forging, Wire Bobbin, Wire Spool, Wire Rope, Spring Wires, Welding Wire, Coiled Wire Etc. |
| STANDARD | UNS | WERKSTOFF NR. |
| Cu-Ni 95/5 | C70400 | – |
Melting Point – Liquidus°F |
2050 |
Densitylb/cu in. at 68°F |
0.323 |
Specific Gravity |
8.94 |
Electrical Conductivity% IACS at 68°F |
14 |
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F |
37 |
Coefficient of Thermal Expansion 68-57210?6 per °F (68 – 572°F) |
9.7 |
Specific Heat CapacityBtu/ lb /°F at 68°F |
0.09 |
Modulus of Elasticity in Tensionksi |
17000 |
Modulus of Rigidityksi |
6400 |
Yes, Copper-nickel 95/5 bars and rods are suitable for hygienic and sanitary applications due to their antimicrobial properties, corrosion resistance, and non-toxic nature, making them ideal for water and food-related systems.
Yes, Copper-nickel 95/5 bars and rods can be recycled after use. Their high recyclability allows them to be reprocessed without significant loss of properties, promoting sustainability and resource efficiency.
Yes, Copper-nickel 95/5 bars and rods are suitable for potable water applications due to their excellent corrosion resistance, biofouling resistance, and durability, ensuring safe and long-lasting performance in water systems.
Copper-Nickel 90/10 Forgings are extensively used in applications that demand strength, corrosion resistance, and long service. In the marine industry, they are utilized in ship construction, seawater piping, pumps, valves, and heat exchangers because of their resistance to biofouling and corrosion by seawater. They are utilized in condenser tubes, fittings, and cooling systems in power plants and desalination plants wherever reliability under aggressive conditions is critical. In chemical processing, they assure resistance against corrosive liquids. With high thermal conductivity, great weldability, and stress corrosion cracking resistance, Copper-Nickel 90/10 forgings are the first choice for demanding applications in marine, industrial, and power generation
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kanish Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Dubai, UAE
