Kanish Metals is a renowned producer and supplier of Monel K500 Bars and Rods, located in Dubai, UAE, with high-performance nickel-copper alloy materials that cater to stringent industries’ demands. With a reputation for producing materials with strength, corrosion resistance, and reliability, Kanish Metals ensures international quality standards on all Monel K500 bars and rods. These alloys are precision-engineered for uses involving excellent mechanical properties and superior resistance to seawater and chemical environments. With customized solutions, quick delivery, and competitive costs in mind, Kanish Metals is the go-to supplier for Monel K500 in the UAE and internationally.
Monel K500 is a precipitation-hardened nickel-copper alloy with about 63% nickel content, 30% copper, and small amounts of aluminum and titanium. These aspects bring greater strength and hardness compared to Monel 400 without sacrificing corrosion resistance. The alloy provides tensile strength of as much as 1100 MPa, yield strength of approximately 790 MPa, and elongation of roughly 20%. Monel K500 retains its properties in sub-zero and high-temperature environments. It also resists stress corrosion cracking as well as erosion and is best suited for extremely corrosive as well as high-stress conditions.
| Standard | ASTM B865, ASME SB865 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S | Ti |
| Monel K500 | 63.0 min | 0.5 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.010 max | 0.35 – 0.85 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Monel K500 | 2.4375 | N05500 |
Yes, Monel Alloy K500 rods are highly corrosion-resistant, particularly in marine and chemical environments. They offer excellent resistance to seawater, acids, and other harsh conditions.
Yes, Monel K500 bars can be customized in size and length to meet specific requirements. They are available in various dimensions and can be tailored for different applications.
Monel K500 bars are known for their exceptional corrosion resistance, high strength, and excellent fatigue and thermal-fatigue strength. They also offer good machinability and weldability in demanding environments.
Monel K500 Rods and Bars find extensive applications in marine, chemical, aerospace, and oil & gas sectors where simultaneous high strength and corrosion resistance is needed. Some typical applications are pump shafts, propeller shafts for marine use, valve parts, fasteners, springs, and oil well equipment. The alloy is perfect for use where the atmosphere is exposed to seawater, acidic chemicals, and under high-pressure conditions. It is suited for use in sour gas service and finds application in instrumentation and sensors. The resistance to wear and spark makes Monel K500 an appropriate choice for safety-related components in explosive or flammable atmospheres.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
