Kanish Metals is a reputable manufacturer and exporter of Incoloy Hollow Bars in Dubai, UAE, supplying high-quality products for applications demanding corrosion-resistant and high-temperature alloys. Incoloy hollow bars are accurately engineered with superior dimensional accuracy and are well-suited for machining into components subjected to harsh environments. Famous for their strength, high quality, and resistance to chemical attack and oxidation, these bars are manufactured in different grades like Incoloy 800, 825, etc. Kanish Metals works with industries including oil & gas, chemical processing, marine, and power generation with customized solutions with prompt delivery and international standards compliance.
Incoloy Hollow Bars consist of nickel-iron-chromium alloys with the inclusion of molybdenum, copper, and titanium to provide corrosion resistance and mechanical strength. The bars possess tensile strength ranging from 550–850 MPa and yield strength ranging from 220–450 MPa, based on the grade of the bar. They work exceedingly well at high temperatures and in acidic environments, resisting stress corrosion cracking, pitting, and crevice corrosion. The hollow shape facilitates weight reduction and effective machining into components like tubes, bushings, and pressure parts, with good strength and durability over a broad range of temperatures.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
Yes, Incoloy Hollow Bars can be welded using appropriate techniques, such as gas tungsten arc welding (GTAW). Proper welding procedures ensure strong, durable joints with minimal risk of cracking or corrosion.
Incoloy Hollow Bars are highly resistant to corrosion due to their alloy composition, and typically do not require additional coatings. However, in extremely aggressive environments, further protective measures may be considered for enhanced durability.
Incoloy Hollow Bars are used extensively in situations where corrosion resistance, high strength, and thermal stability are critical. Common applications are heat exchanger parts, condenser tubing, marine components, chemical process equipment, oil & gas drilling tools, and nuclear reactor piping. Hollow structure renders them particularly ideal for the production of shafts, cylinders, and tubing systems where minimized weight and machining effectiveness are paramount. The bars are best used in sour gas services, seawater systems, and high-temperature industrial applications where conventional alloys could weaken or fail under pressure and chemical exposure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
