Kanish Metals is a well-known manufacturer and exporter in Dubai, UAE, supplying superior Stainless Steel 430 Hollow Bars for numerous industrial uses. Renowned for precision engineering, reliability, and compliance with international standards, Kanish Metals has guaranteed that every product is of high performance and reliability. Stainless Steel 430 Hollow Bars are well known for their good resistance to corrosion, excellent formability, and attractive looks. By maintaining a firm belief in quality, on-time delivery, and customer satisfaction, Kanish Metals is supporting various industries with superior-quality stainless steel solutions.
Stainless Steel 430 Hollow Bars are ferritic stainless steel with approximately 16–18% chromium and negligible nickel content. They offer superior oxidation and stress corrosion cracking resistance in mildly aggressive environments. They have good tensile strength, moderate hardness, and excellent thermal conductivity with stable dimensions. The mechanical properties of these bars qualify them for structural and decorative use. With balanced strength and composition, SS 430 Hollow Bars are durable as well as cost-effective to meet the corrosion resistance and machinability requirements at low alloying costs.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Range : Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 430 | 0.12 | 18.0 | 1.25 | – | 0.06 | 0.15 | 1.00 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 430 | 552 | 379 | 25 | 262 |
| Hollow Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
SS 430 offers good corrosion resistance in mildly corrosive environments but is less resistant than austenitic stainless steels like SS 304 or 316. It is more prone to corrosion in harsh environments, especially those with high chloride content.
SS 430 hollow bars typically range in outer diameters from 20mm to 300mm and wall thicknesses from 2mm to 30mm. Tolerances vary but are generally within ±0.5mm for diameter and ±0.2mm for wall thickness, depending on the manufacturer.
Stainless Steel 430 Hollow Bars find extensive application in a number of industries owing to their resilience and corrosion resistance. They are widely used in architectural constructions, decorative uses, kitchen appliances, and automotive trim components because of their shiny finish and malleability. They are also utilized in furnace parts, heat exchanger tubes, and food processing machinery where strength and cleanliness are essential. These bars are also utilized in chemical treatment units, railings, and mechanical constructions. Their performance, cost-effectiveness, and looks make SS 430 Hollow Bars a practical option for commercial and industrial use.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
